Panasonic TH-55VF2 55-inch video wall displayPanasonic
Video WallsSKU TH-55VF2

Panasonic VF2 Series 55-inch Video Wall Display – TH-55VF2

The Panasonic TH-55VF2 is a 55-inch Full HD LCD video wall display with a 0.44 mm bezel for multi-screen walls. It suits signage, monitoring rooms and public facilities, with 500 nits brightness, 1,100:1 contrast and 24-hour operation. Procure.ae supplies the TH-55VF2 across the UAE.

The TH-55VF2 uses a 1920 x 1080 LCD panel with direct-lit LED backlighting and local dimming, rated at 500,000:1 dynamic contrast and 1,100:1 contrast. Its advanced anti-glare surface, with 28% haze, reduces reflections from sunlight and lighting, which the manufacturer says makes it suitable for monitoring rooms and public facilities. The panel has an 8 ms response time and 178-degree horizontal and vertical viewing angles, and the display is rated for 24 hours a day.

In a multi-screen wall, the 0.44 mm bezel-to-bezel gap keeps split images natural, and the manufacturer requires a gap of 0.5 mm or more between installed units. DIGITAL LINK, based on HDBaseT technology, carries audio, video and control over long distances on one CAT5e or higher STP cable and can daisy-chain up to 10 units. The display also supports PJLink, RS-232C control and failover and failback between two inputs, and it runs in landscape or portrait without changing color or operating life.

Screen Size
55 inch
Resolution
1920 x 1080 (Full HD)
Brightness
500 nits
Type
Video Wall Display
  • Ultra-narrow bezel
  • Advanced anti-glare panel
  • Local dimming LED backlight
Price
On request · best price
1
Download spec sheet (PDF) Manufacturer datasheet (PDF)
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request

Key features

01
Ultra-narrow bezel
0.44 mm bezel-to-bezel on the top, bottom, left and right, with a gap of 0.5 mm or more needed between installed units.
02
Advanced anti-glare panel
a 28% haze surface treatment diffuses sunlight and lighting reflections.
03
Local dimming LED backlight
direct-lit LED backlighting gives 500,000:1 dynamic contrast and 1,100:1 contrast.
04
DIGITAL LINK daisy chain
up to 10 units connect on one CAT5e or higher STP cable, carrying audio, video and control.
05
Failover and failback
switching between two system inputs prevents image interruptions in transport signage.
06
Landscape or portrait use
designed for either orientation without affecting color, brightness or operating life.
07
24-hour operation
rated for 24 hours a day, with moving content advised to limit image retention.
08
Multiple inputs and control
HDMI, DisplayPort, DVI-D, PC In, RS-232C and PJLink support for integration with control systems.

Specifications

26 specifications
General
Key Features0.44 mm bezel, anti-glare panel, 500,000:1 dynamic contrast, DIGITAL LINK daisy chain up to 10 units, failover and failback inputs, landscape or portrait use, 24/7 operation, PJLink support
ModelTH-55VF2
TypeVideo Wall Display
Display
Aspect Ratio16:9
BacklightDirect-lit LED with local dimming
Bezel Size0.44 mm bezel-to-bezel
Brightness500 nits
Contrast Ratio1,100:1
OrientationLandscape and portrait
Panel TechnologyLCD
Resolution1920 x 1080 (Full HD)
Response Time8 ms
Screen Size55 inch
Viewing Angle178° horizontal / 178° vertical
Performance
Duty Cycle24 hours a day
Audio
Speaker Output20 W (10 W + 10 W), 8 Ω external speaker
Connectivity
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 1, DVI-D In × 2, DisplayPort × 1, PC In (Mini D-Sub 15-pin) × 1, USB 2.0 × 1, RJ45 DIGITAL LINK/LAN × 1
ProtocolsPJLink, RS-232C
Power
Power Consumption165 W (average, on mode)
Standby Power0.5 W
Physical
Dimensions1210.6 x 681.3 x 97.3 mm
FinishAdvanced anti-glare (haze 28%)
Operating Humidity10% to 90% RH
Operating Temperature0 to 40 °C
Weight23.0 kg

Questions

Can’t find your answer? Ask on WhatsApp

Is the TH-55VF2 suitable for a video wall?
Yes. The 0.44 mm bezel-to-bezel design is built for multi-screen video walls, and the manufacturer notes that a gap of 0.5 mm or more is required between displays when several units are installed.
How many TH-55VF2 displays can be daisy-chained?
Up to 10 units can be connected in a DIGITAL LINK daisy chain using one CAT5e or higher STP cable. The manufacturer notes that the number may be limited by the cables and the units used.
Can the TH-55VF2 run in portrait mode?
Yes. The manufacturer states the display is designed for landscape or portrait orientation without affecting color, brightness or operating life. Tilt is listed as vertical only, so plan the mounting angle before installation.
Is the TH-55VF2 rated for 24/7 operation?
Yes. The manufacturer lists an operating time of 24 hours a day. For long periods, the manufacturer recommends showing moving images to help prevent image retention, and notes that burn-in can be gradually rectified by periodically displaying moving images.
Can the TH-55VF2 connect to a control system?
Yes. It has RS-232C serial control, an RJ45 LAN port with PJLink support and IR in and out. The manufacturer notes that a remote control ID setting is needed when one unit in a multi-screen system is operated by remote control.
Can I buy the TH-55VF2 in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
