LG SVM5F Slim Bezel 55-inch Video Wall Display – 55SVM5F-H
The LG 55SVM5F-H is a 55-inch Full HD video wall display with a 0.44 mm even bezel, 500 nits typical brightness and portrait or landscape orientation. It suits control rooms, lobbies and retail walls, and Procure.ae supplies it across the UAE.
The 55SVM5F-H uses a 55-inch IPS panel with 1920 x 1080 Full HD resolution, 500 nits typical brightness, a 1,100:1 contrast ratio and 178 x 178 degree viewing angles. The 8 ms response time (G to G) and the narrow 0.44 mm even bezel suit tiled walls where image continuity matters. The manufacturer rates the panel for 24-hour operation with a 60,000-hour typical life time.
The display has a built-in power supply, a 600 x 400 mm VESA mounting interface and a piggyback OPS slot for an external media player. Control uses RS232C, RJ45 LAN and IR, and the manufacturer lists SuperSign CMS and SuperSign Control software. Compared with the 55VM5E-A, this model specifies a 0.44 mm bezel against 0.9 mm. Model code 55SVM5F-H.AMND is also listed.
Screen Size
55 inch
Resolution
1920 x 1080 (Full HD)
Brightness
500 nits
Type
Video Wall Display
- Slim bezel
- Full HD IPS panel
- Brightness
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Slim bezel
0.44 mm even bezel for narrow tiling
02
Full HD IPS panel
1920 x 1080 resolution with 178 x 178 degree viewing angles
03
Brightness
500 nits typical for indoor video wall use
04
Orientation
portrait and landscape operation
05
Inputs
HDMI (2), DisplayPort, DVI-D and USB 2.0
06
OPS compatible
piggyback slot for an external media player
07
Control
RS232C, RJ45 LAN and IR connections
08
Software
SuperSign CMS and SuperSign Control / Control+
Specifications
23 specificationsGeneral
Key Features0.44 mm even bezel, 16:9 narrow-bezel tiling, Portrait and landscape orientation, OPS-compatible (piggyback), SuperSign CMS support, RS232C and LAN control, Built-in power
Model55SVM5F-H
TypeVideo Wall Display
What's in the BoxRemote controller, power cord, RS232C cable, LAN cable, DP cable, IR receiver, guide bracket, screws, manual
Display
Aspect Ratio16:9
Brightness500 nits
Contrast Ratio1,100:1
OrientationPortrait & Landscape
Panel TechnologyIPS
Resolution1920 x 1080 (Full HD)
Response Time8 ms
Screen Size55 inch
Viewing Angle178 x 178
Connectivity
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 2, DisplayPort In × 1, DVI-D In × 1, USB 2.0 × 1, RS232C In/Out, RJ45 (LAN) In/Out, IR In
Power
Power Consumption200 W (typical), 250 W (maximum)
Standby Power105 W (Smart Energy Saving)
Physical
Dimensions1210.51 x 681.22 x 86.5 mm
Duty Cycle24 hours a day
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
VESA Mount600 x 400 mm
Weight16.8 kg
Questions
Can’t find your answer? Ask on WhatsApp
What is the LG 55SVM5F-H?
The LG 55SVM5F-H is a 55-inch Full HD (1920 x 1080) IPS video wall display with a 0.44 mm even bezel and 500 nits typical brightness. It is built for tiled walls in control rooms, lobbies and retail spaces, and it runs in portrait or landscape orientation.
Can the 55SVM5F-H be mounted in a video wall?
Yes. The display has a 600 x 400 mm VESA mounting interface and ships with a guide bracket and screws. The 0.44 mm even bezel keeps the gaps between panels narrow when several units are tiled together.
Does the 55SVM5F-H support an OPS media player?
Yes. The display is OPS type compatible in piggyback form, so an OPS media player can be fitted to the back of the unit. It also has RS232C, RJ45 LAN and IR control connections for a central control system.
What software does the 55SVM5F-H work with?
The manufacturer lists SuperSign CMS for content management and SuperSign Control and Control+ for control and monitoring. A remote controller is included, and the display can also be managed over RJ45 LAN.
What power does the 55SVM5F-H need?
It runs on 100–240 V AC, 50/60 Hz with built-in power. Typical consumption is 200 W and the maximum is 250 W, with 105 W in Smart Energy Saving mode. It is rated for 0 to 40 °C operation and 10% to 80% humidity.
