The LG 55SVM5F-H is a 55-inch Full HD video wall display with a 0.44 mm even bezel, 500 nits typical brightness and portrait or landscape orientation. It suits control rooms, lobbies and retail walls, and Procure.ae supplies it across the UAE.
The 55SVM5F-H uses a 55-inch IPS panel with 1920 x 1080 Full HD resolution, 500 nits typical brightness, a 1,100:1 contrast ratio and 178 x 178 degree viewing angles. The 8 ms response time (G to G) and the narrow 0.44 mm even bezel suit tiled walls where image continuity matters. The manufacturer rates the panel for 24-hour operation with a 60,000-hour typical life time.
The display has a built-in power supply, a 600 x 400 mm VESA mounting interface and a piggyback OPS slot for an external media player. Control uses RS232C, RJ45 LAN and IR, and the manufacturer lists SuperSign CMS and SuperSign Control software. Compared with the 55VM5E-A, this model specifies a 0.44 mm bezel against 0.9 mm. Model code 55SVM5F-H.AMND is also listed.
| Key Features | 0.44 mm even bezel, 16:9 narrow-bezel tiling, Portrait and landscape orientation, OPS-compatible (piggyback), SuperSign CMS support, RS232C and LAN control, Built-in power |
| Model | 55SVM5F-H |
| Type | Video Wall Display |
| What's in the Box | Remote controller, power cord, RS232C cable, LAN cable, DP cable, IR receiver, guide bracket, screws, manual |
| Aspect Ratio | 16:9 |
| Brightness | 500 nits |
| Contrast Ratio | 1,100:1 |
| Orientation | Portrait & Landscape |
| Panel Technology | IPS |
| Resolution | 1920 x 1080 (Full HD) |
| Response Time | 8 ms |
| Screen Size | 55 inch |
| Viewing Angle | 178 x 178 |
| Input Voltage | 100–240 V AC, 50/60 Hz |
| Ports | HDMI In × 2, DisplayPort In × 1, DVI-D In × 1, USB 2.0 × 1, RS232C In/Out, RJ45 (LAN) In/Out, IR In |
| Power Consumption | 200 W (typical), 250 W (maximum) |
| Standby Power | 105 W (Smart Energy Saving) |
| Dimensions | 1210.51 x 681.22 x 86.5 mm |
| Duty Cycle | 24 hours a day |
| Operating Humidity | 10% to 80% RH |
| Operating Temperature | 0 to 40 °C |
| VESA Mount | 600 x 400 mm |
| Weight | 16.8 kg |
This sheet is compiled from the product data held on procure.ae. For fully accurate and up-to-date figures, always refer to the manufacturer’s own specification sheet or datasheet for this model.
Specifications are provided by the manufacturer and may change without notice.
