YealinkMeeting Room SolutionsSKU VCM38
Yealink VCM38 Ceiling Conference Microphone – VCM38
The Yealink VCM38 is a ceiling conference microphone with eight built-in microphones for 360-degree voice pickup. It is rated at -45 dB ±1 dB sensitivity and 100 dB SPL maximum, and runs on PSE 54 V or PoE 48 V. Procure.ae can confirm current UAE availability or recommend the current successor model.
The VCM38 uses eight built-in microphones to pick up voices across 360 degrees. The manufacturer describes it as giving clearer and smoother audio for conference rooms. Its frequency response runs from 100 Hz to 16 kHz, with a signal-to-noise ratio of 60 dBA at 1 kHz, and a maximum sound pressure level of 100 dB SPL at 1 kHz with THD below 1%.
The VCM38 is a ceiling microphone for conference rooms, powered by PSE 54 V (0.56 A) or PoE 48 V (0.27 A). It measures 127.3 x 127.3 x 66.3 mm (W x D x H) and operates at 0 to 40 °C with 5% to 90% humidity. The VCM38 is discontinued, so confirm current availability or a successor model with Procure.ae before planning an installation.
Type
Ceiling Conference Microphone
- Eight built-in microphones
- Frequency response
- Signal-to-noise ratio
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Eight built-in microphones
Eight microphones provide 360-degree voice pickup.
02
Frequency response
100 Hz to 16 kHz, according to the manufacturer.
03
Signal-to-noise ratio
60 dBA at 1 kHz.
04
Microphone sensitivity
-45 dB ±1 dB at 1 kHz (0 dB = 1 V/Pa).
05
Flexible power
PSE 54 V (0.56 A) or PoE 48 V (0.27 A).
06
Body dimensions
127.3 x 127.3 x 66.3 mm (W x D x H).
Specifications
14 specificationsGeneral
Key FeaturesCeiling mount, 8 built-in microphones, 360° pickup, 100 Hz to 16 kHz, 60 dBA SNR, PSE or PoE
ModelVCM38
TypeCeiling Conference Microphone
Audio
Coverage Pattern360°
Frequency Response100 Hz to 16 kHz
Max SPL100 dB SPL @ 1 kHz, THD < 1%
Microphone Type8 built-in microphones
Sensitivity-45 dB ±1 dB @ 1 kHz (0 dB = 1 V/Pa)
Signal-to-Noise Ratio60 dBA @ 1 kHz
Connectivity
Input VoltagePSE 54 V, 0.56 A or PoE 48 V, 0.27 A
Physical
Dimensions127.3 x 127.3 x 66.3 mm (W x D x H)
MountingCeiling
Operating Humidity5% to 90%
Operating Temperature0 to 40 °C
Downloads
Manufacturer documents for the Yealink VCM38 Ceiling Conference Microphone – VCM38 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What is the Yealink VCM38?
The Yealink VCM38 is a ceiling conference microphone with eight built-in microphones for 360-degree voice pickup. The manufacturer lists a frequency response of 100 Hz to 16 kHz and a signal-to-noise ratio of 60 dBA.
Is the VCM38 a ceiling microphone?
Yes. The manufacturer describes the VCM38 as a ceiling microphone for conference rooms. It measures 127.3 x 127.3 x 66.3 mm, so check the ceiling space before installation. The manufacturer's specifications do not state a ceiling tile type or mounting bracket, so confirm this with Procure.ae.
How is the VCM38 powered?
The VCM38 is powered by PSE 54 V, 0.56 A or PoE 48 V, 0.27 A. Use a PSE or PoE source that matches one of these ratings for your installation.
What are the sensitivity and maximum sound level of the VCM38?
Sensitivity is -45 dB ±1 dB at 1 kHz, with 0 dB equal to 1 V/Pa. The maximum sound pressure level is 100 dB SPL at 1 kHz with THD below 1%, according to the manufacturer.
What operating conditions does the VCM38 support?
The manufacturer rates the VCM38 for operating temperatures of 0 to 40 °C and operating humidity of 5% to 90%. The VCM38 is discontinued, so confirm availability before planning a project.
