ViewSonicDigital SignageSKU CDE8631-1C
ViewSonic CDE31 Series 86-inch 4K Digital Signage Display – CDE8631-1C
The ViewSonic CDE8631-1C is an 86-inch 4K UHD commercial display for corporate, retail, education and healthcare spaces. It has 500 nits of brightness, Android 14 upgradeable to Android 16, 8 GB RAM and an OPS slot for PC modules. Procure.ae supplies the CDE8631-1C across the UAE, with quotes, delivery and installation.
The CDE8631-1C uses a 3840 x 2160 (4K UHD) TFT LCD panel with DLED backlight, 500 nits brightness and an 8 ms response time. Its 1,200:1 typical contrast ratio rises to 5,000:1 with DCR enabled, and viewing angles are 178 degrees horizontally and vertically. A quad-core processor with 8 GB RAM and 32 GB storage runs Android 14, which can be upgraded to Android 16. The built-in OPS slot accepts an OPS computer module, and two 16 W speakers provide audio.
The CDE8631-1C is designed for digital signage and meeting spaces in landscape or portrait orientation, on a 600 x 400 mm VESA pattern. ViewSonic Manager provides centralised remote control, and the display supports static IP configuration and a web-based interface. It integrates with leading Pro AV control systems through RS-232, SPDIF and RJ45 ports. Compared with the CDE9831-1C, it is an 86-inch model with a 15.9 mm bezel and lighter 42 kg net weight.
Screen Size
86 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Type
Digital Signage Display
- Native 4K UHD panel
- Android 14 platform
- OPS slot
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Native 4K UHD panel
3840 x 2160 resolution at 500 nits brightness, with a 5,000:1 DCR contrast ratio.
02
Android 14 platform
Upgradeable to Android 16, with 8 GB RAM and 32 GB storage.
03
OPS slot
Built-in OPS slot for an OPS computer module.
04
Built-in speakers
Dual 16 W speakers with 3.5 mm audio in and out.
05
Wireless presentation
AirSync wireless presentation with a Wi-Fi slot.
06
Remote management
ViewSonic Manager for centralised control and static IP configuration.
07
Pro AV integration
RS-232, SPDIF and two RJ45 ports for control systems and AV routing.
08
Landscape and portrait
Operates in both orientations on a 600 x 400 mm VESA pattern.
Specifications
30 specificationsGeneral
Key FeaturesAndroid 14, OPS slot for PC modules, AirSync wireless presentation, ViewSonic Manager remote management, USB media playback, landscape and portrait, 4K UHD, 24/7 operation
ModelCDE8631-1C
TypeDigital Signage Display
Display
Aspect Ratio16:9
BacklightDLED
Bezel Size15.9 mm
Brightness500 nits
Contrast Ratio1,200:1 (typical; 5,000:1 with DCR)
Display TypeCommercial LCD display
OrientationLandscape and portrait
Panel TechnologyLCD
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size86 inch
Viewing Angle178° horizontal / 178° vertical
Performance
Operating SystemAndroid 14 (upgradeable to Android 16)
ProcessorQuad-core ARM Cortex-A73
RAM8 GB
Storage32 GB
Audio
Audio2 × 16 W built-in speakers, 3.5 mm audio in/out
Connectivity
Input Voltage100–240 V AC ±10%
OPS SlotOPS slot × 1
PortsOPS slot × 1, Wi-Fi slot × 1, RS-232 × 1, SPDIF × 1, RJ45 × 2, USB 2.0 × 1, USB 3.2 Gen 1 × 1, USB-C × 1 (DisplayPort 1.2)
Power
Power Consumption104.21 W
Physical
Dimensions1930.8 x 1101.7 x 68 mm
Operating Humidity20% to 80% RH
Operating Temperature0 to 40 °C
VESA Mount600 x 400 mm
Weight42 kg
Compliance
CertificationsENERGY STAR
Downloads
Manufacturer documents for the ViewSonic CDE31 Series 86-inch 4K Digital Signage Display – CDE8631-1C — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Does the CDE8631-1C have an OPS slot?
Yes. It has one OPS slot for an OPS computer module, so you can run a PC-based player or application on the display. The slot is listed alongside a Wi-Fi slot, two RJ45 ports and a USB-C port with DisplayPort 1.2.
Can the CDE8631-1C run portrait signage?
Yes. The display supports both landscape and portrait orientation, which suits vertical menus and wayfinding. Confirm the orientation and mount with your installer before fitting the panel. Portrait mounting is useful in corridors, lifts and entrances where vertical content works well.
What operating system does the CDE8631-1C use?
It runs Android 14 on a quad-core processor with 8 GB RAM and 32 GB storage. The platform is upgradeable to Android 16. ViewSonic Manager supports remote management for multi-display installations.
What VESA mount does the CDE8631-1C need?
It uses a 600 x 400 mm VESA pattern. The panel measures 1930.8 x 1101.7 x 68 mm and weighs 42 kg net, so the mount must be rated for that weight. Procure.ae can recommend a suitable installation.
Does the CDE8631-1C work with Pro AV control systems?
Yes. It integrates with leading Pro AV control systems through its RS-232 port, SPDIF output and RJ45 ports. The RJ45 ports support 10/100M for USB-C and 1000M for OPS, which helps with networked control.
Can I buy the CDE8631-1C in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
