ViewSonic CDE31 Series 86-inch 4K Digital Signage Display – CDE8631-1C
The ViewSonic CDE8631-1C is an 86-inch 4K UHD commercial display for corporate, retail, education and healthcare spaces. It has 500 nits of brightness, Android 14 upgradeable to Android 16, 8 GB RAM and an OPS slot for PC modules. Procure.ae supplies the CDE8631-1C across the UAE, with quotes, delivery and installation.
The CDE8631-1C uses a 3840 x 2160 (4K UHD) TFT LCD panel with DLED backlight, 500 nits brightness and an 8 ms response time. Its 1,200:1 typical contrast ratio rises to 5,000:1 with DCR enabled, and viewing angles are 178 degrees horizontally and vertically. A quad-core processor with 8 GB RAM and 32 GB storage runs Android 14, which can be upgraded to Android 16. The built-in OPS slot accepts an OPS computer module, and two 16 W speakers provide audio.
The CDE8631-1C is designed for digital signage and meeting spaces in landscape or portrait orientation, on a 600 x 400 mm VESA pattern. ViewSonic Manager provides centralised remote control, and the display supports static IP configuration and a web-based interface. It integrates with leading Pro AV control systems through RS-232, SPDIF and RJ45 ports. Compared with the CDE9831-1C, it is an 86-inch model with a 15.9 mm bezel and lighter 42 kg net weight.
Key features
Specifications
| Key Features | Android 14, OPS slot for PC modules, AirSync wireless presentation, ViewSonic Manager remote management, USB media playback, landscape and portrait, 4K UHD, 24/7 operation |
| Model | CDE8631-1C |
| Type | Digital Signage Display |
| Aspect Ratio | 16:9 |
| Backlight | DLED |
| Bezel Size | 15.9 mm |
| Brightness | 500 nits |
| Contrast Ratio | 1,200:1 (typical; 5,000:1 with DCR) |
| Display Type | Commercial LCD display |
| Orientation | Landscape and portrait |
| Panel Technology | LCD |
| Resolution | 3840 x 2160 (4K UHD) |
| Response Time | 8 ms |
| Screen Size | 86 inch |
| Viewing Angle | 178° horizontal / 178° vertical |
| Operating System | Android 14 (upgradeable to Android 16) |
| Processor | Quad-core ARM Cortex-A73 |
| RAM | 8 GB |
| Storage | 32 GB |
| Audio | 2 × 16 W built-in speakers, 3.5 mm audio in/out |
| Input Voltage | 100–240 V AC ±10% |
| OPS Slot | OPS slot × 1 |
| Ports | OPS slot × 1, Wi-Fi slot × 1, RS-232 × 1, SPDIF × 1, RJ45 × 2, USB 2.0 × 1, USB 3.2 Gen 1 × 1, USB-C × 1 (DisplayPort 1.2) |
| Power Consumption | 104.21 W |
| Dimensions | 1930.8 x 1101.7 x 68 mm |
| Operating Humidity | 20% to 80% RH |
| Operating Temperature | 0 to 40 °C |
| VESA Mount | 600 x 400 mm |
| Weight | 42 kg |
| Certifications | ENERGY STAR |
☎ +971 4 546 5041 · WhatsApp · ✉ info@procure.ae · 🔗 View product page
This sheet is compiled from the product data held on procure.ae. For fully accurate and up-to-date figures, always refer to the manufacturer’s own specification sheet or datasheet for this model.
Specifications are provided by the manufacturer and may change without notice.
Pricing is quote-based. Contact Procure for current pricing and availability.
Delivery across the UAE and beyond, installation on request and manufacturer-backed warranty.
