SMART HDMI 2.1 Ultra High Speed Cable – HD-1021AOC
The SMART HD-1021AOC is a 10 m (33 ft) HDMI 2.1 active optical cable for connecting a source to SMART Board interactive displays. It supports 48 Gbps bandwidth, 8K at 60 Hz and eARC, and its jacket is plenum rated. Procure.ae supplies this SMART cable across the UAE, with delivery and installation.
The cable is an ultra high speed certified HDMI 2.1 model with a 48 Gbps maximum bandwidth. It carries up to 8K at 60 Hz, 4K at 144 Hz and 1080p at 240 Hz, and supports HDR formats including Dolby Vision, HDR10+, Static HDR and HLG. Supported features include EDID, CEC, ALLM, VRR, DSC, ARC and eARC. Audio passes through as 2-channel PCM, multichannel LPCM up to 192 kHz over 32 channels, DTS-X and Dolby Atmos. Both connectors are HDMI Type-A male with 24-carat gold-plated contacts.
The cable is active optical with a hybrid fiber and copper conductor, and it is directional, running from the source end to the display end. It is bus-powered from the connected source, so it needs no external power supply. It is backward compatible with HDMI 2.0 and earlier, and its bend radius is 60 mm (2 3/8 in). The manufacturer lists a 1-year limited equipment warranty, with terms that vary by region.
Type
HDMI Cable
Weight
522 g
- Full 8K support
- HDR formats
- Surround audio
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Full 8K support
Carries up to 8K at 60 Hz and 4K at 144 Hz over a 48 Gbps maximum bandwidth.
02
HDR formats
Supports Dolby Vision, HDR10+, Static HDR and HLG.
03
Surround audio
Passes multichannel LPCM up to 192 kHz / 32 channels, DTS-X and Dolby Atmos.
04
Plenum-rated jacket
The CMP jacket is rated for plenum installation.
05
Bus-powered design
Draws its power from the connected source, so no external power is needed.
06
Length and diameter
The cable is 10 m (33 ft) long with a 6 mm (1/4 in) outer diameter.
Specifications
16 specificationsGeneral
CompatibilitySMART Board interactive displays with an HDMI 2.1 connector; backward compatible with HDMI 2.0 and earlier
Key FeaturesActive optical, 8K60, 4K144, eARC, ALLM, VRR, DSC, HDR10+, Dolby Vision
ModelSMART HDMI Cable HD-1021AOC
TypeHDMI Cable
Performance
Bandwidth48 Gbps
Audio
AudioMultichannel LPCM up to 192 kHz / 32 channels, DTS-X, Dolby Atmos
Connectivity
Cable StandardHDMI 2.1, Ultra High Speed certified
ConductorHybrid fiber and copper
Connector TypeHDMI Type-A male (19-pin), both ends
Jacket MaterialCMP (plenum rated)
Power
Power Consumption25 mW (max), bus-powered
Physical
Length10 m (33 ft)
Operating Humidity5% to 90% RH
Operating Temperature0 to 60 °C
Weight522 g
Compliance
Warranty1 year
Downloads
Manufacturer documents for the SMART HDMI 2.1 Ultra High Speed Cable – HD-1021AOC — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Will this cable work with my SMART Board display?
Yes, if the display has an HDMI 2.1 connector, because the manufacturer lists compatibility with SMART Board interactive displays with that connector. The cable is also backward compatible with HDMI 2.0 and earlier equipment.
Does the cable need a power supply?
No, the cable is bus-powered, drawing 4.5 V to 5.5 V from the connected source. The manufacturer lists no external power requirement and a maximum power consumption of 25 mW.
Is the cable suitable for plenum installation?
Yes, the jacket is CMP and plenum rated. The manufacturer lists an operating temperature of 0 to 60 °C and a relative humidity range of 5% to 90%, so check those limits against the installation space.
