The SMART HD-1021AOC is a 10 m (33 ft) HDMI 2.1 active optical cable for connecting a source to SMART Board interactive displays. It supports 48 Gbps bandwidth, 8K at 60 Hz and eARC, and its jacket is plenum rated. Procure.ae supplies this SMART cable across the UAE, with delivery and installation.
The cable is an ultra high speed certified HDMI 2.1 model with a 48 Gbps maximum bandwidth. It carries up to 8K at 60 Hz, 4K at 144 Hz and 1080p at 240 Hz, and supports HDR formats including Dolby Vision, HDR10+, Static HDR and HLG. Supported features include EDID, CEC, ALLM, VRR, DSC, ARC and eARC. Audio passes through as 2-channel PCM, multichannel LPCM up to 192 kHz over 32 channels, DTS-X and Dolby Atmos. Both connectors are HDMI Type-A male with 24-carat gold-plated contacts.
The cable is active optical with a hybrid fiber and copper conductor, and it is directional, running from the source end to the display end. It is bus-powered from the connected source, so it needs no external power supply. It is backward compatible with HDMI 2.0 and earlier, and its bend radius is 60 mm (2 3/8 in). The manufacturer lists a 1-year limited equipment warranty, with terms that vary by region.
| Compatibility | SMART Board interactive displays with an HDMI 2.1 connector; backward compatible with HDMI 2.0 and earlier |
| Key Features | Active optical, 8K60, 4K144, eARC, ALLM, VRR, DSC, HDR10+, Dolby Vision |
| Model | SMART HDMI Cable HD-1021AOC |
| Type | HDMI Cable |
| Bandwidth | 48 Gbps |
| Audio | Multichannel LPCM up to 192 kHz / 32 channels, DTS-X, Dolby Atmos |
| Cable Standard | HDMI 2.1, Ultra High Speed certified |
| Conductor | Hybrid fiber and copper |
| Connector Type | HDMI Type-A male (19-pin), both ends |
| Jacket Material | CMP (plenum rated) |
| Power Consumption | 25 mW (max), bus-powered |
| Length | 10 m (33 ft) |
| Operating Humidity | 5% to 90% RH |
| Operating Temperature | 0 to 60 °C |
| Weight | 522 g |
| Warranty | 1 year |
This sheet is compiled from the product data held on procure.ae. For fully accurate and up-to-date figures, always refer to the manufacturer’s own specification sheet or datasheet for this model.
Specifications are provided by the manufacturer and may change without notice.
