PhilipsDigital SignageSKU 75BDL4550D/00
Philips 75-inch 4K UHD Android Digital Signage Display – 75BDL4550D/00
The Philips 75BDL4550D/00 is a 74.5-inch 4K UHD digital signage display that runs Android 8.0 with built-in dual-band Wi-Fi. It suits 24/7 lobby, retail and campus signage, with 3840 x 2160 resolution, 500 nits brightness and 3 GB RAM. Procure.ae supplies it in the UAE, with delivery and installation.
The 75BDL4550D/00 combines a 3840 x 2160 IPS panel with 500 cd/m² brightness, 1,200:1 typical contrast and an 8 ms typical response time. Its 178-degree viewing angles suit wide rooms. Android 8.0 runs on a 2 x Cortex-A53 and 2 x Cortex-A73 processor, with 3 GB RAM and 32 GB eMMC storage on board. The 2 x 10 W RMS speakers handle announcements and short audio clips.
Connect a PC or media player through three HDMI 2.0 inputs, a DisplayPort 1.2 input or a DVI-I input, and use the USB 2.0 ports for media. Dual-band 2.4 GHz and 5 GHz Wi-Fi with dual aerials is built in, and mPCIe 4G/LTE antenna connectors are fitted for a 4G/LTE module. RJ45 and RS232C ports allow remote management. The display is rated for landscape or portrait use at 24/7, and the 600 x 400 mm VESA pattern fits standard wall mounts.
Screen Size
74.5 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Type
Digital Signage Display
- Ultra HD IPS panel
- Built-in Android
- Dual-band Wi-Fi
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Ultra HD IPS panel
3840 x 2160 resolution on a 74.5-inch 16:9 screen.
02
Built-in Android
Android 8.0 on a Cortex-A53 and Cortex-A73 processor.
03
Dual-band Wi-Fi
2.4 GHz and 5 GHz with dual aerials, 802.11a/b/g/n.
04
Onboard memory
3 GB RAM and 32 GB eMMC storage.
05
Bright, wide viewing
500 cd/m² brightness and 178-degree viewing angles.
06
Always-on operation
Landscape or portrait placement rated for 24/7 use.
07
OPS and 4G ready
An OPS slot and mPCIe 4G/LTE antenna connectors.
08
Remote management
RJ45 and RS232C network control with IR in and out.
Specifications
30 specificationsGeneral
Key FeaturesAndroid 8.0, dual-band Wi-Fi, 4G/LTE antenna connectors, OPS slot, tiling up to 10 x 15, Smart Power, Pixel Shift, RJ45 and RS232C control
Model75BDL4550D/00
TypeDigital Signage Display
What's in the BoxRemote control with AAA batteries, RS232 cables, AC power cord, IR sensor cable, quick start guide
Display
Aspect Ratio16:9
Brightness500 nits
Color Depth1.07 billion colours
Contrast Ratio1,200:1
Panel TechnologyIPS
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size74.5 inch
Viewing Angle178° horizontal, 178° vertical
Performance
GraphicsARM Mali G51
Operating SystemAndroid 8.0
Processor2 x Cortex-A53 + 2 x Cortex-A73
RAM3 GB
Storage32 GB eMMC
Audio
Speaker Output2 x 10 W RMS
Connectivity
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 3, DisplayPort In × 1, DVI-I In × 1, USB 2.0 × 2, HDMI Out × 1, DisplayPort Out × 1, RJ45, RS232C
Wi-FiDual-band 2.4 GHz and 5 GHz (802.11a/b/g/n)
Power
Power Consumption224 W (typical), 375 W (max)
Standby Power<0.5 W
Physical
Operating Humidity20% to 80% RH
Operating Temperature0 to 40 °C
VESA Mount600 x 400 mm
Weight36.3 kg
Compliance
Warranty3 years
Downloads
Manufacturer documents for the Philips 75-inch 4K UHD Android Digital Signage Display – 75BDL4550D/00 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Does the 75BDL4550D/00 run Android?
Yes. The manufacturer lists Android 8.0 as the operating system, running on a 2 x Cortex-A53 and 2 x Cortex-A73 processor with 3 GB RAM and 32 GB eMMC storage. The product page describes the display as designed for running Android apps.
Does the 75BDL4550D/00 have built-in Wi-Fi?
Yes. The display has dual-band Wi-Fi covering 2.4 GHz and 5 GHz, with dual aerials and 802.11a/b/g/n support. It also has mPCIe 4G/LTE antenna connectors for a 4G/LTE module, so cellular connectivity can be added as a backup route.
Is the 75BDL4550D/00 suitable for a lobby?
Yes. The 500 cd/m² brightness and 178-degree horizontal and vertical viewing angles suit lobbies, reception areas and corridors where people view the screen from different positions. It is rated for 24/7 operation in landscape or portrait.
Can I mount the 75BDL4550D/00 on a wall?
Yes. It uses a 600 x 400 mm VESA pattern with M8 fixings, and the listed weight is 36.3 kg. Use a wall bracket rated for that weight and have a qualified installer fit it. Procure.ae offers installation across the UAE.
Can the 75BDL4550D/00 be controlled remotely?
Yes. It has RJ45 and RS232C network control ports, IR in and out, and hidden, lockable keyboard control. A remote control, IR sensor cable and RS232 cable are included, so the display can be managed over the network or serial control.
