LG Wallpaper 55-inch OLED Video Wall Display – 55EJ5K

The LG 55EJ5K is a 55-inch Full HD OLED video wall display from the LG Wallpaper series, built for digital signage and video walls. It offers a 150,000:1 contrast ratio, a 120 Hz refresh rate and a 0.9 mm off-bezel design for seamless tiling. Procure.ae can confirm availability of the LG 55EJ5K across the UAE.

The 55EJ5K uses a 55-inch OLED panel with a native resolution of 1920 x 1080 (Full HD) and a 16:9 aspect ratio. Its 120 Hz refresh rate and 1 ms (G to G) response time suit moving content. Brightness is rated at 150 nits at APL 100% and 400 nits at APL 25%, with a 150,000:1 contrast ratio and BT.709 120% color gamut. Viewing angles are 178 degrees horizontal and vertical, and the manufacturer rates the panel at 30,000 hours typical life.

The display supports portrait and landscape orientation and can be daisy-chained, with HDMI or DisplayPort input and DisplayPort output. Built-in webOS 4.0 with SuperSign CMS, SuperSign Control+ and Crestron Connected support lets operators schedule content and manage units across a network. RS232C, RJ45 LAN and IR control ports allow integration with control systems. Its narrow off-bezel frame suits video walls where tile edges must be kept small.

Screen Size
55 inch
Resolution
1920 x 1080 (Full HD)
Brightness
150 nits (APL 100%) / 400 nits (APL...
Type
OLED Video Wall Display
  • Self-emissive OLED
  • Full HD resolution
  • 120 Hz refresh
Price
On request · best price
1
Download spec sheet (PDF) Manufacturer datasheet (PDF)
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request

Key features

01
Self-emissive OLED
55-inch OLED panel with a 150,000:1 contrast ratio.
02
Full HD resolution
1920 x 1080 native resolution on a 16:9 screen.
03
120 Hz refresh
120 Hz refresh rate with 1 ms (G to G) response time.
04
Narrow off-bezel
0.9 mm off-bezel design for seamless video wall tiling.
05
Built-in webOS
webOS 4.0 with 16 GB internal eMMC storage.
06
Network control
RS232C, RJ45 LAN and IR control, with SNMP and Crestron Connected support.
07
Content management
SuperSign CMS, Control+ and Mobile CMS with local content scheduling.
08
Daisy chain
HDMI or DisplayPort input with DisplayPort output for chaining units.

Specifications

28 specifications
General
ApplicationVideo walls, digital signage
Key FeaturesOLED self-emissive panel, Full HD 1920 x 1080, 120 Hz, 0.9 mm off-bezel, webOS 4.0, SuperSign CMS, Crestron Connected, Video Tag
Model55EJ5K
TypeOLED Video Wall Display
Display
Aspect Ratio16:9
Bezel Size0.9 mm (off-bezel)
Brightness150 nits (APL 100%) / 400 nits (APL 25%)
Color Depth1.07 billion colors
Color GamutBT.709 120%
Contrast Ratio150,000:1
Panel TechnologyOLED
Refresh Rate120 Hz
Resolution1920 x 1080 (Full HD)
Response Time1 ms (G to G)
Screen Size55 inch
Viewing Angle178° horizontal / 178° vertical
Performance
Operating SystemwebOS 4.0
Storage16 GB (eMMC)
Connectivity
ConnectivityRS232C, RJ45 LAN, IR, daisy chain (HDMI/DP in, DP out)
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 1, DisplayPort In × 1, DisplayPort Out × 1, RS232C In/Out, RJ45 LAN In/Out, IR In/Out, USB 2.0 × 2
Physical
Dimensions1220.3 x 696.8 x 4.9 mm (display head)
Duty Cycle18 hours/day, 7 days (moving content only)
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
Shipping Weight23.1 kg (packed)
Weight6.5 kg (display head)
Compliance
CertificationsCB / NRTL, FCC Class A, CE, KC

Downloads

Manufacturer documents for the LG Wallpaper 55-inch OLED Video Wall Display – 55EJ5K — datasheets, manuals, drawings and certificates.

Questions

Can’t find your answer? Ask on WhatsApp

Is the LG 55EJ5K a 4K display?
No. The manufacturer's specifications list a native resolution of 1920 x 1080 (Full HD) on this 55-inch OLED panel. Buyers who need 4K detail for close viewing should compare the 4K LG models in the same EJ5E and EV5E video wall range before ordering.
Can the LG 55EJ5K be used in a video wall?
Yes. The 0.9 mm off-bezel design, tile mode setting, screen rotation and gapless playback support video wall layouts. Units can be controlled over RS232C, RJ45 LAN or IR, and sync over the local network.
What mounting does the LG 55EJ5K need?
The manufacturer's specifications do not state a VESA pattern for this model. The display head connects to a separate signage box with FFC cables, and the package includes four wall fixers and a wall fixer install guide.
Which operating system and content software does the LG 55EJ5K use?
It runs webOS 4.0 with 16 GB of internal eMMC storage. Content can be managed with SuperSign CMS, SuperSign Control+ and Mobile CMS, and the unit supports local content scheduling and fail-over.
What power and operating conditions does it need?
It runs on 100-240 V AC, 50/60 Hz with built-in power. Operating temperature is 0 to 40 °C and operating humidity is 10% to 80% RH. The manufacturer rates operation at 18 hours a day, 7 days a week, for moving content only.
