LGVideo WallsSKU 55VM5R-H
LG VM5R 55-inch Slim Bezel Video Wall – 55VM5R-H
The LG 55VM5R-H is a 55-inch Full HD LCD video wall display with 500 nits typical brightness and a 1.7mm bezel-to-bezel design, built for 24/7 operation. It is made for tiling into video walls and digital signage, with daisy chain input over HDMI or DisplayPort. Procure.ae supplies the LG 55VM5R-H in the UAE.
Core capabilities include a 55-inch ADS panel at 1920 x 1080 with 500 nits typical brightness, a 1,200:1 contrast ratio and 178-degree horizontal and vertical viewing angles. The 8ms response time, 16.7 million colours and NTSC 72% colour gamut support clear playback, and the panel is rated for a minimum of 50,000 hours of life. Portrait and landscape orientation are both supported, so the display can be used in either layout.
The LG 55VM5R-H is built for tiled video walls and digital signage, with tile mode settings, gapless playback and daisy chain connections. It runs webOS 6.1 and works with SuperSign CMS, SuperSign Control+, SuperSign Cloud and Crestron Connected, plus SNMP and Wake on LAN. Mounting uses a VESA 600 x 400 mm interface, and the head weighs 20.1 kg. Model codes 55VM5R-H.AMAD and 55VM5R-H.AUS are listed for this product.
Screen Size
55 inch
Resolution
1920 x 1080 (Full HD)
Brightness
500 nits
Type
Video Wall Display
- 55-inch Full HD panel
- 1.7mm bezel-to-bezel design
- 24/7 operation
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
55-inch Full HD panel
1920 x 1080 resolution with 500 nits typical brightness and 1,200:1 contrast.
02
1.7mm bezel-to-bezel design
A slim panel-to-panel bezel for tiled video wall layouts.
03
24/7 operation
Rated for continuous use, with a minimum lifetime of 50,000 hours.
04
Daisy chain connectivity
HDMI or DP input with DP output for chaining displays.
05
Portrait and landscape orientation
Screen rotation and external input rotation are both supported.
06
webOS 6.1 with SuperSign
Runs webOS 6.1 and works with SuperSign CMS and Control+ content management.
07
Tile mode and gapless playback
Tile Mode Setting and gapless playback support video wall content.
08
Remote management and control
LAN and RS232C control, SNMP, Wake on LAN and Crestron Connected.
Specifications
40 specificationsGeneral
Key FeaturesTile mode, DP and HDMI daisy chain, failover, local content scheduling, gapless playback, control manager and SNMP, Wake on LAN, screen rotation
Model55VM5R-H
TypeVideo Wall Display
What's in the BoxRemote controller with 2 batteries, power cord, RS-232C cable, LAN cable, DP cable, IR receiver, manual
Display
Aspect Ratio16:9
BacklightDirect LED
Bezel Size1.7 mm bezel-to-bezel (1.2 mm top/left, 0.5 mm bottom/right)
Brightness500 nits
Color Depth16.7 million
Color GamutNTSC 72%
Contrast Ratio1,200:1
OrientationLandscape, Portrait
Panel TechnologyADS
Refresh Rate60 Hz
Resolution1920 x 1080 (Full HD)
Response Time8 ms
Screen Size55 inch
Viewing Angle178° (H) / 178° (V)
Performance
Operating SystemwebOS 6.1
Storage8 GB
Audio
Audio OutYes
DisplayPortDisplayPort in and out
Connectivity
EthernetRJ45 in × 1, RJ45 out
HDMI InputsHDMI In × 2
Input Voltage100–240 V AC, 50/60 Hz
Serial PortRS-232C in and out
USB PortsUSB 2.0 Type-A × 1
Power
Power Consumption170 W (typical), 200 W (max)
Standby Power0.5 W
Physical
Dimensions1212.7 x 683.5 x 90.1 mm
Duty Cycle24/7
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
Shipping Dimensions1393 x 955 x 303 mm
Shipping Weight28.3 kg
Surface ProtectionAnti-glare (25% haze)
VESA Mount600 x 400 mm
Weight20.1 kg
Compliance
CertificationsCB / NRTL, FCC Class B, CE, KC, Energy Star 8.0
IP RatingIP5X (tested)
Downloads
Manufacturer documents for the LG VM5R 55-inch Slim Bezel Video Wall – 55VM5R-H — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Is the LG 55VM5R-H a 4K display?
No. The 55VM5R-H has a native resolution of 1920 x 1080 (Full HD). Its 1.7mm bezel-to-bezel design is aimed at tiled video walls, and it supports portrait and landscape orientation.
How bright is the LG 55VM5R-H?
It has 500 nits typical brightness, a 1,200:1 contrast ratio and a 500,000:1 dynamic contrast ratio. Viewing angles are 178 degrees horizontal and vertical, with an 8ms response time (G to G).
Can the LG 55VM5R-H run 24/7?
Yes. It is rated for 24/7 operation with a minimum lifetime of 50,000 hours. Its operating temperature range is 0 °C to 40 °C, with humidity of 10% to 80% (non-condensing).
Can the LG 55VM5R-H be wall-mounted?
Yes. It has a VESA standard mount interface of 600 x 400 mm and a handle for moving the unit. The head weighs 20.1 kg, and the packed weight is 28.3 kg.
Can the LG 55VM5R-H be managed remotely or controlled from a computer?
Yes. It supports LAN (RJ45) and RS232C control, SNMP, Wake on LAN and Crestron Connected. It also works with SuperSign CMS and Control+ for content management, and lists Group Manager and Control Manager for multi-display control.
