BiampMeeting Room SolutionsSKU Parlé TCM-XEX
Biamp Parlé TCM-XEX White Ceiling Expansion Microphone – 920-00500-20000
The Biamp Parlé TCM-XEX is a white, low-profile ceiling expansion microphone for larger meeting rooms. It works with a TCM-X or TCM-XA host and is not a standalone device. It uses Beamtracking across four 90° zones for 360° pickup, and it connects over one CAT5 cable. Procure.ae supplies it across the UAE.
The TCM-XEX extends the coverage of an existing Parlé system. Beamtracking across four 90° zones captures voices over a full 360° area, and it mixes active talkers automatically without manual lobe aiming. The microphone uses one AEC channel, even when daisy-chained, so the host system's channel count stays the same. A single CAT5 connection links it to the host microphone's network box.
The manufacturer states that the TCM-XEX works as an expansion microphone with a TCM-X or TCM-XA and is not a standalone device. It has a low-profile, 150 mm (5.90-inch) white ceiling design, with an LED mute status indicator that shows the microphone state during meetings. It is certified for Microsoft Teams and Zoom, and it is UL 2043 plenum rated for installation in ceiling plenums.
Type
Ceiling Expansion Microphone
Weight
340 g (0.7 lbs)
- 360° expansion coverage
- Low-profile white design
- Expansion microphone
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
360° expansion coverage
four 90° Beamtracking zones capture voices across the full room.
02
Low-profile white design
the 150 mm (5.90 in) ceiling body is surface-mounted and discreet.
03
Expansion microphone
works with a TCM-X or TCM-XA host and is not a standalone device.
04
Single CAT5 connection
one cable links the microphone to the host network box.
05
One AEC channel
uses one AEC channel per microphone, including when daisy-chained.
06
Mute status LED
an LED mute status indicator shows the microphone state during meetings.
07
UC platform certification
certified for Microsoft Teams and Zoom.
08
Plenum rated and compliant
UL 2043 plenum rated, UL listed, CE marked, RoHS compliant and TAA compliant.
Specifications
12 specificationsGeneral
CompatibilityBiamp TCM-X or TCM-XA (expansion); Microsoft Teams; Zoom
Key FeaturesBeamtracking, 360° pickup, LED mute indicator, one AEC channel per microphone, daisy-chain support, plenum rated
ModelParlé TCM-XEX
TypeCeiling Expansion Microphone
Audio
Polar PatternBeamtracking, four 90° zones (360° coverage)
Connectivity
ConnectivityCAT5 to host network box, up to 10 m (33 ft) from DSP host
Physical
ColorWhite
Form FactorLow-profile ceiling, 150 mm (5.90 in)
Operating Temperature0 to 40 °C
Weight340 g (0.7 lbs)
Compliance
CertificationsTAA compliant; UL 2043 plenum rated; UL listed; CE marked; RoHS compliant
Warranty5 years
Downloads
Manufacturer documents for the Biamp Parlé TCM-XEX White Ceiling Expansion Microphone – 920-00500-20000 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Can the Biamp Parlé TCM-XEX be used on its own?
No. The manufacturer describes the TCM-XEX as an expansion microphone that functions with a TCM-X or TCM-XA. It is not a standalone device, so it needs one of those host microphones.
How far can the TCM-XEX be from its host device?
The manufacturer states a maximum distance of 33 feet (10 meters) between the TCM-XEX and the DSP host device. It connects over one CAT5 cable to the host microphone's network box.
Is the TCM-XEX compatible with Microsoft Teams and Zoom?
Yes. The manufacturer states that the TCM-XEX is certified for Microsoft Teams and Zoom. It works through its TCM-X or TCM-XA host, whose network box connects to the room's conferencing system over CAT5, so the room can run on those UC platforms.
How is the TCM-XEX installed?
It is a surface-mounted, low-profile ceiling microphone with a 150 mm (5.90-inch) body in white. It connects to the host network box with one CAT5 cable, and the manufacturer rates it UL 2043 plenum rated.
Can the TCM-XEX be daisy-chained?
Yes. The manufacturer states that the TCM-XEX uses only one AEC channel per microphone, even when daisy-chaining a TCM-XEX. This keeps the channel count of the host system unchanged. The network box has onboard DSP, and each microphone in the chain is connected with one CAT5 link, so the system stays simple to configure as coverage grows.
Can I buy the Biamp Parlé TCM-XEX in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
