BiampMeeting Room SolutionsSKU Parlé TCM-1
Biamp Parlé TCM-1 White Pendant Conferencing Microphone – TCM-1
The Biamp Parlé TCM-1 is a white pendant conferencing microphone for meeting spaces. Its Beamtracking array covers 360 degrees with three 120-degree zones and is powered over PoE (IEEE 802.3at Class 3, 15.4 W). Procure.ae supplies the Parlé TCM-1 across the UAE.
The Parlé TCM-1 uses an 8-element digital array with Beamtracking technology to follow active talkers across three 120-degree microphone zones. Sensitivity is above 70 dB (94 dB SPL, 1 kHz), dynamic range is 92 dB A-weighted and frequency response runs from 150 Hz to 16 kHz (±3 dB). The plenum box includes built-in DSP for Beamtracking processing, and an LED indicator shows mute status. The system is evaluated to UL 2043 and is suitable for air-handling spaces.
The TCM-1 suits meeting spaces where ceiling-mounted pickup is needed. It connects over RJ-45 through its plenum box, which is powered by PoE (IEEE 802.3at Class 3, 15.4 W). For larger rooms, up to two TCM-1EX expansion microphones can be daisy-chained, with up to 100 m (330 feet) between devices. The TCM-1A adds a built-in PoE+ amplifier to the same Beamtracking design.
Type
Pendant Conferencing Microphone
Weight
0.2 kg (microphone); 1.1 kg (plenum...
- Beamtracking Pickup
- 360-Degree Coverage
- Built-In Plenum DSP
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Beamtracking Pickup
Beamtracking technology tracks and mixes speech from active talkers anywhere in the room.
02
360-Degree Coverage
Three 120-degree microphone zones cover the full room.
03
Built-In Plenum DSP
The plenum box includes DSP for Beamtracking signal processing.
04
Daisy-Chain Expansion
Supports up to two TCM-1EX expansion microphones.
05
Air-Handling Rated
Suitable for air-handling spaces and evaluated to UL 2043.
06
LED Mute Indicator
An LED shows the mute state at a glance.
07
Global Compliance
CE marked, UL listed, RoHS compliant and TAA compliant.
08
5-Year Warranty
Backed by a 5-year warranty.
Specifications
17 specificationsGeneral
Key FeaturesBeamtracking, 360-degree pickup, LED mute indicator, plenum DSP, TAA compliant
ModelParlé TCM-1
TypePendant Conferencing Microphone
Audio
Dynamic Range92 dB, A-weighted
Frequency Response150 Hz – 16 kHz (±3 dB)
Max SPL106 dB (at 0.5% THD)
Microphone8-element digital array
Polar PatternBeamformed, three 120-degree zones
Sensitivity> 70 dB (94 dB SPL, 1 kHz)
Connectivity
ConnectivityRJ-45 (PoE); 100 m (330 feet) between devices
Connector TypeCustom 2-pin, 10 ft (3 m) cable
ExpansionDaisy-chain up to two expansion microphones
PoEIEEE 802.3at Class 3 (15.4 W)
Physical
ColorWhite
Weight0.2 kg (microphone); 1.1 kg (plenum box)
Compliance
CertificationsFCC Part 15B, CE, UL / C-UL, RoHS, UL 2043 (air-handling)
Warranty5 years
Downloads
Manufacturer documents for the Biamp Parlé TCM-1 White Pendant Conferencing Microphone – TCM-1 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
How wide is the pickup of the Parlé TCM-1?
The Parlé TCM-1 covers 360 degrees with three 120-degree microphone zones. Beamtracking technology tracks and mixes speech from active talkers anywhere in the room. The microphone has a sensitivity above 70 dB at 94 dB SPL, 1 kHz.
Does the Parlé TCM-1 need PoE?
Yes. The plenum box is powered by PoE (IEEE 802.3at Class 3, 15.4 W) and connects over RJ-45 to the network switch. The microphone connects to the plenum box through a custom 2-pin connector with a 10 ft (3 m) cable.
Can the Parlé TCM-1 be expanded for a larger room?
Yes. Up to two TCM-1EX expansion microphones can be daisy-chained to a TCM-1 system, with up to 100 m (330 feet) between devices. This extends Beamtracking pickup to a bigger meeting space.
Is the Parlé TCM-1 suitable for air-handling spaces?
Yes. The Parlé TCM-1 is evaluated to the requirements of UL 2043 and is suitable for use in air-handling spaces. It is also CE marked, UL listed, RoHS compliant and TAA compliant.
