Biamp Devio SCR-25CX conferencing hub with TCM-XEX ceiling microphoneBiamp
Meeting Room SolutionsSKU Devio SCR-25CX

Biamp Devio Conferencing Hub with Ceiling Microphone – SCR-25CX Black

The Biamp Devio SCR-25CX is a conferencing hub bundled with a TCM-XEX ceiling microphone that has 360-degree coverage. It sends a PC's web conference to one in-room display through pass-through HDMI, with output up to 3840 x 2160 (4K UHD) at 30 Hz. It suits meeting rooms with a ceiling microphone, and Procure.ae supplies it across the UAE.

The Devio SCR-25 hub works with PCs running Microsoft Teams, Zoom, Google Meet, BlueJeans and Skype for Business, on both Windows and Mac. Auto Setup validates device connections, adjusts room levels and sets speaker EQ. The hub supports up to 3840 x 2160 (4K UHD) at 30 Hz on output port 1 and supports Bluetooth wireless technology. It runs on a 24 V DC, 60 W supply and weighs 0.9 kg. Alternate part numbers are 930-00459-00019 and 930-00459-00025.

The SCR-25CX suits meeting rooms with a ceiling microphone and a single in-room display. Two monitors can take USB video through DisplayLink, which needs a driver on the laptop for Windows 7, 8, 8.1 and 10. Speakers connect through HDMI audio, the built-in 20 W amplifier or RCA line out, and the hub mounts under a table with the included bracket. Compared with the SCR-25C (pendant microphone) and SCR-25T (tabletop microphone), the SCR-25CX uses a TCM-XEX ceiling microphone.

Resolution
3840 x 2160 (4K UHD) at 30 Hz, outp...
Type
Conferencing Hub with Ceiling Micro...
Weight
0.9 kg
  • Web conferencing compatibility
  • Auto Setup
  • Pass-through HDMI
Price
On request · best price
1
Download spec sheet (PDF) Manufacturer datasheet (PDF)
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request

Key features

01
Web conferencing compatibility
Works with PCs running Microsoft Teams, Zoom, Google Meet, BlueJeans and Skype for Business.
02
Auto Setup
Validates device connections, adjusts room levels and sets speaker EQ.
03
Pass-through HDMI
Drives one in-room display, or two monitors with USB video through DisplayLink.
04
Ceiling microphone
Includes a TCM-XEX ceiling microphone with 360-degree coverage.
05
4K output
Supports up to 3840 x 2160 (4K UHD) at 30 Hz on output port 1 only.
06
Speaker options
Connects through HDMI audio, a built-in 20 W amplifier or RCA line out.
07
Remote management
Monitored over SNMP or the Devio System Administration Utility, which schedules firmware updates.
08
Under-table mounting
Includes a bracket for under-the-table installation.

Specifications

17 specifications
General
CompatibilityWindows and Mac PCs; Microsoft Teams, Zoom, Google Meet, BlueJeans, Skype for Business
Key FeaturesAuto Setup, Bluetooth wireless, SNMP management, pass-through HDMI or DisplayLink dual monitors, built-in 20 W amplifier, under-table mount, TAA compliant, 5-year warranty
ModelDevio SCR-25CX
TypeConferencing Hub with Ceiling Microphone
What's in the BoxDevio SCR-25 hub, TCM-XEX ceiling microphone
Display
Resolution3840 x 2160 (4K UHD) at 30 Hz, output port 1 only
Audio
Impedance100 Ω (unbalanced)
MicrophoneTCM-XEX ceiling, 360-degree coverage
Connectivity
ConnectivityBluetooth wireless
PortsHDMI, RCA line out, RJ-45 Ethernet
ProtocolsSNMP
Power
Power Source24 V DC, 60 W
Physical
MountingUnder-table bracket included
Operating Temperature0 to 40 °C
Weight0.9 kg
Compliance
CertificationsFCC Part 15B, UL and C-UL, CE, RoHS, TAA compliant
Warranty5 years

Downloads

Manufacturer documents for the Biamp Devio Conferencing Hub with Ceiling Microphone – SCR-25CX Black — datasheets, manuals, drawings and certificates.

Questions

Can’t find your answer? Ask on WhatsApp

Does the Devio SCR-25CX work with Microsoft Teams and Zoom?
Yes. The SCR-25CX works with PCs running Microsoft Teams, Zoom, Google Meet, BlueJeans and Skype for Business, on Windows and Mac. It uses standard audio drivers, and single-display HDMI pass-through is driverless. Two-monitor USB video needs the DisplayLink driver installed on the laptop.
What room size is the Devio SCR-25CX suited to?
The manufacturer's specifications do not state a maximum room size. The SCR-25CX suits rooms with a single in-room display, and its ceiling microphone has 360-degree coverage. Room layout and display size should be confirmed for each installation.
Can the SCR-25CX be mounted under a table?
Yes. The hub includes a bracket for under-the-table installation. It weighs 0.9 kg, runs on a 24 V DC, 60 W supply and operates from 0 to 40 °C. The network connection uses RJ-45 with Cat 5e or higher Ethernet cable.
Can IT teams manage the SCR-25CX remotely?
Yes. The hub can be monitored and managed remotely over SNMP or with the Devio System Administration Utility. The utility can schedule firmware updates and deploy them to multiple Devio units across a site.
Can I buy the Devio SCR-25CX in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
