BiampMeeting Room SolutionsSKU Devio DCM-1
Biamp Beamtracking Pendant Microphone, White – Devio DCM-1
The Biamp Devio DCM-1 in white is a beamtracking pendant microphone for Devio conferencing systems. It uses three 120-degree zones for 360-degree coverage, three LED mute indicators and a single-cable RJ-45 connection phantom-powered by an SCR-20 or SCR-25. Procure.ae supplies the Biamp Devio DCM-1 in the UAE.
The DCM-1 tracks and mixes conversations around the table with Beamtracking technology, using three 120-degree zones for 360 degrees of coverage. Three LED mute status indicators show mute state at a glance, and four selectable elevation angle modes plus a user-adjustable microphone height help set pickup for each table. The pendant weighs 0.17 kg and draws less than 1 W. Manufacturer model codes are 920-00488-10000 and 920-00488-20000.
The DCM-1 installs with a single cable, and an additional RJ-45 port daisy-chains a second DCM-1, with a maximum of two microphones per chain. The plenum box is included and is evaluated to UL 2043 for use in air handling spaces. An optional tile bridge mounting accessory is available. The Devio DTM-1 tabletop microphone is the other microphone in the same Devio family.
Type
Pendant Microphone
Weight
0.17 kg (pendant microphone); 0.39 ...
- Beamtracking pickup
- 360-degree coverage
- LED mute indicators
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Beamtracking pickup
Tracks and mixes conversations around the table automatically.
02
360-degree coverage
Three 120-degree zones cover the full table.
03
LED mute indicators
Three LED mute status indicators on the pendant.
04
Elevation angle modes
Four selectable elevation angle modes and user-adjustable height.
05
Single-cable installation
Connects to the SCR-20 or SCR-25 unit over one RJ-45 cable.
06
Daisy-chain RJ-45
Connects a second DCM-1 for up to two microphones per chain.
07
Air handling rated
Evaluated to UL 2043 for use in air handling spaces.
08
TAA compliant
Compliant with the US Trade Agreement Act, with a 2-year warranty.
Specifications
16 specificationsGeneral
CompatibilityDevio SCR-20 and SCR-25 systems
ControlsThree LED mute indicators, user-adjustable height, four elevation angle modes
Key FeaturesBeamtracking, three 120-degree zones, three LED mute indicators, four elevation modes, single-cable installation, daisy-chain RJ-45, TAA compliant
ModelDevio DCM-1
TypePendant Microphone
Audio
Coverage PatternThree 120-degree zones (360 degrees)
Connectivity
ConnectivityRJ-45 daisy-chain, up to two microphones per chain
Connector TypeRJ-45
Power
Power Consumption< 1 W
Power SourcePhantom power from SCR-20/SCR-25
Physical
ColorWhite
MountingPendant; optional tile bridge accessory
Operating Temperature0 to 40 °C
Weight0.17 kg (pendant microphone); 0.39 kg (plenum box)
Compliance
CertificationsTAA compliant, FCC Part 15B, CE, UL and C-UL, RoHS, UL 2043 (air handling spaces)
Warranty2 years
Downloads
Manufacturer documents for the Biamp Beamtracking Pendant Microphone, White – Devio DCM-1 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Is the Devio DCM-1 compatible with the SCR-20 and SCR-25?
Yes. The DCM-1 plenum box connects to an SCR-20 or SCR-25 unit over RJ-45 and draws phantom power from it, consuming less than 1 W. The manufacturer describes the installation as a single-cable process, with one RJ-45 run from the unit to the plenum box.
How many Devio DCM-1 microphones can be daisy-chained?
Two. Each DCM-1 has an additional RJ-45 port for daisy-chain connection to another DCM-1, with a maximum of two microphones per daisy chain. The second DCM-1 connects to the first plenum box over RJ-45, and the first connects to the SCR-20 or SCR-25.
Can the DCM-1 be used in air handling spaces?
Yes. The manufacturer states the DCM-1 is evaluated to UL 2043 and is suitable for use in air handling spaces. It is also FCC Part 15B, CE, UL and C-UL, and RoHS compliant.
Which tables suit the DCM-1?
The DCM-1 suits conference tables where a pendant microphone is preferred. Three 120-degree zones give 360-degree coverage, and the height and four elevation modes can be adjusted to suit the table.
Does the DCM-1 come with a mounting kit?
The plenum box is included with the microphone, and it carries the RJ-45 connections. An optional tile bridge mounting accessory is available if you need to mount the unit on a tile bridge.
Can I buy the Devio DCM-1 in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
