Biamp Beamtracking Pendant Microphone, White – Devio DCM-1

The Biamp Devio DCM-1 in white is a beamtracking pendant microphone for Devio conferencing systems. It uses three 120-degree zones for 360-degree coverage, three LED mute indicators and a single-cable RJ-45 connection phantom-powered by an SCR-20 or SCR-25. Procure.ae supplies the Biamp Devio DCM-1 in the UAE.

The DCM-1 tracks and mixes conversations around the table with Beamtracking technology, using three 120-degree zones for 360 degrees of coverage. Three LED mute status indicators show mute state at a glance, and four selectable elevation angle modes plus a user-adjustable microphone height help set pickup for each table. The pendant weighs 0.17 kg and draws less than 1 W. Manufacturer model codes are 920-00488-10000 and 920-00488-20000.

The DCM-1 installs with a single cable, and an additional RJ-45 port daisy-chains a second DCM-1, with a maximum of two microphones per chain. The plenum box is included and is evaluated to UL 2043 for use in air handling spaces. An optional tile bridge mounting accessory is available. The Devio DTM-1 tabletop microphone is the other microphone in the same Devio family.

Type

Pendant Microphone

Weight

0.17 kg (pendant microphone); 0.39 kg (plenum box)

Key features

Beamtracking pickup

Tracks and mixes conversations around the table automatically.

360-degree coverage

Three 120-degree zones cover the full table.

LED mute indicators

Three LED mute status indicators on the pendant.

Elevation angle modes

Four selectable elevation angle modes and user-adjustable height.

Single-cable installation

Connects to the SCR-20 or SCR-25 unit over one RJ-45 cable.

Daisy-chain RJ-45

Connects a second DCM-1 for up to two microphones per chain.

Air handling rated

Evaluated to UL 2043 for use in air handling spaces.

TAA compliant

Compliant with the US Trade Agreement Act, with a 2-year warranty.

Specifications

General
Compatibility	Devio SCR-20 and SCR-25 systems
Controls	Three LED mute indicators, user-adjustable height, four elevation angle modes
Key Features	Beamtracking, three 120-degree zones, three LED mute indicators, four elevation modes, single-cable installation, daisy-chain RJ-45, TAA compliant
Model	Devio DCM-1
Type	Pendant Microphone

Audio
Coverage Pattern	Three 120-degree zones (360 degrees)

Connectivity
Connectivity	RJ-45 daisy-chain, up to two microphones per chain
Connector Type	RJ-45

Power
Power Consumption	< 1 W
Power Source	Phantom power from SCR-20/SCR-25

Physical
Color	White
Mounting	Pendant; optional tile bridge accessory
Operating Temperature	0 to 40 °C
Weight	0.17 kg (pendant microphone); 0.39 kg (plenum box)

Compliance
Certifications	TAA compliant, FCC Part 15B, CE, UL and C-UL, RoHS, UL 2043 (air handling spaces)
Warranty	2 years
