BenQMeeting Room SolutionsSKU TWY31
BenQ InstaShare Wireless Screen Sharing Button – TWY31
The BenQ TWY31 is an InstaShare button for one-click wireless screen sharing to BenQ boards. It supports input up to 4K30P, Wi-Fi 802.11ac on the 5 GHz band and AES-256 wireless encryption. It is a silver USB Type-C accessory. Procure.ae supplies the BenQ TWY31 in the UAE.
The TWY31 lets users wirelessly share a screen, camera feed or file on the display from anywhere in the room, as the manufacturer describes. The wireless transmission frame rate is up to 60 fps depending on the environment, at 1080P60 or 4K30P. The button runs on DC 5 V from a USB Type-C connection and draws a maximum of 4.5 W at full load. Stereo audio is sent at 16-bit, 48 kHz, using InstaShare 2 wireless screen sharing.
The TWY31 is listed as a BenQ Board accessory, and its compatibility list covers casting and BYOM setups. The manufacturer lists casting compatibility with RP03, RP03 v1, RM03, RM03A, RP04, RM04, RE03A, RE03N1 and RE03N2 models, and some of these need a Wi-Fi dongle. Its operating range is 0 to 40 °C, with storage from -10 to 60 °C, in a compact 67 x 67 x 23.2 mm housing.
Resolution
Up to 4K30P
Type
Wireless Screen Sharing Button
- One-click sharing
- InstaShare 2 casting
- 4K30P input
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
One-click sharing
Wirelessly shares a screen, camera feed or file on the display.
02
InstaShare 2 casting
Uses InstaShare 2 wireless screen sharing on BenQ boards.
03
4K30P input
TX button input resolution up to 4K30P.
04
60 fps transmission
Wireless transmission frame rate up to 60 fps, depending on environment.
05
AES-256 encryption
WPA2/3 Personal, WPA2 Enterprise and AES-256 wireless security.
06
USB Type-C power
Powered over USB Type-C at DC 5 V, 0.9 A minimum.
Specifications
17 specificationsGeneral
CompatibilityCasting: RP03, RP03 v1, RM03, RM03A, RP04, RM04, RE03A, RE03N1, RE03N2 (some with Wi-Fi dongles)
Key FeaturesOne-click screen sharing, InstaShare 2, screen, camera or file sharing, up to 60 fps, AES-256 encryption
ModelTWY31
TypeWireless Screen Sharing Button
Display
Refresh RateUp to 60 fps (1080P60/4K30P)
ResolutionUp to 4K30P
Performance
Storage Conditions-10 to 60 °C, 10% to 80% RH non-condensing
Audio
AudioStereo, 16-bit 48 kHz
Connectivity
Connector TypeUSB Type-C
Wi-FiIEEE 802.11ac 5 GHz, 2T2R MIMO
Power
Power Consumption4.5 W (max, full load)
Power SourceDC 5 V ±10%, 0.9 A minimum
Physical
ColorSilver
Dimensions67 x 67 x 23.2 mm
Operating Humidity5% to 90% RH non-condensing
Operating Temperature0 to 40 °C
Compliance
Security FeaturesWPA2/3 Personal, WPA2 Enterprise, AES-256
Downloads
Manufacturer documents for the BenQ InstaShare Wireless Screen Sharing Button – TWY31 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Which BenQ boards work with the TWY31?
The manufacturer lists casting compatibility with RP03, RP03 v1, RM03, RM03A, RP04, RM04, RE03A, RE03N1 and RE03N2, and BYOM compatibility with several RP and RM models. Some models need a Wi-Fi dongle, so check the pairing for your board before ordering.
Does the TWY31 need a Wi-Fi dongle?
Some compatible models need a dongle. The manufacturer lists the TDY31 dongle for the RM03A and the WD02AT dongle for the RE03N2 and RM04. Procure.ae can confirm the correct setup for your board before you order.
What frame rate and input resolution does the TWY31 support?
The TWY31 transmits at up to 60 fps depending on the environment, at 1080P60 or 4K30P. Its TX button input resolution is up to 4K30P, and it uses 802.11ac on the 5 GHz band with 2T2R MIMO.
Can I buy the TWY31 in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
