BenQ InstaShare Wireless Screen Sharing Button – TWY31
The BenQ TWY31 is an InstaShare button for one-click wireless screen sharing to BenQ boards. It supports input up to 4K30P, Wi-Fi 802.11ac on the 5 GHz band and AES-256 wireless encryption. It is a silver USB Type-C accessory. Procure.ae supplies the BenQ TWY31 in the UAE.
The TWY31 lets users wirelessly share a screen, camera feed or file on the display from anywhere in the room, as the manufacturer describes. The wireless transmission frame rate is up to 60 fps depending on the environment, at 1080P60 or 4K30P. The button runs on DC 5 V from a USB Type-C connection and draws a maximum of 4.5 W at full load. Stereo audio is sent at 16-bit, 48 kHz, using InstaShare 2 wireless screen sharing.
The TWY31 is listed as a BenQ Board accessory, and its compatibility list covers casting and BYOM setups. The manufacturer lists casting compatibility with RP03, RP03 v1, RM03, RM03A, RP04, RM04, RE03A, RE03N1 and RE03N2 models, and some of these need a Wi-Fi dongle. Its operating range is 0 to 40 °C, with storage from -10 to 60 °C, in a compact 67 x 67 x 23.2 mm housing.
Key features
Specifications
| Compatibility | Casting: RP03, RP03 v1, RM03, RM03A, RP04, RM04, RE03A, RE03N1, RE03N2 (some with Wi-Fi dongles) |
| Key Features | One-click screen sharing, InstaShare 2, screen, camera or file sharing, up to 60 fps, AES-256 encryption |
| Model | TWY31 |
| Type | Wireless Screen Sharing Button |
| Refresh Rate | Up to 60 fps (1080P60/4K30P) |
| Resolution | Up to 4K30P |
| Storage Conditions | -10 to 60 °C, 10% to 80% RH non-condensing |
| Audio | Stereo, 16-bit 48 kHz |
| Connector Type | USB Type-C |
| Wi-Fi | IEEE 802.11ac 5 GHz, 2T2R MIMO |
| Power Consumption | 4.5 W (max, full load) |
| Power Source | DC 5 V ±10%, 0.9 A minimum |
| Color | Silver |
| Dimensions | 67 x 67 x 23.2 mm |
| Operating Humidity | 5% to 90% RH non-condensing |
| Operating Temperature | 0 to 40 °C |
| Security Features | WPA2/3 Personal, WPA2 Enterprise, AES-256 |
