Yealink UVC85-BYOD 4K conference camera kit with CP50 speakerphoneYealink

Yealink UVC85 BYOD 4K Conference Camera Kit – UVC85-BYOD

The Yealink UVC85-BYOD is a 4K conference camera kit for medium and large meeting rooms. It pairs the intelligent UVC85 camera with the CP50 conference speakerphone for plug-and-play BYOD meetings. Pan is ±100°, tilt is +30° and -90°, and the effective focal length is 3.4 mm to 40.4 mm. Procure.ae supplies it across the UAE.

The UVC85 camera outputs video up to 4K, with pan of ±100° and tilt of +30° and -90°. Its effective focal length runs from 3.4 mm to 40.4 mm at F/1.8 to F/3.6, and white balance can be set to auto tracking, manual or one-push. Shutter speed ranges from 1/60 to 1/10000 second. The kit adds the CP50 conference speakerphone, so camera and audio arrive together for medium and large rooms.

The kit suits BYOD meeting rooms where participants connect their own laptops or phones and join calls on the platform their organisation uses. The camera runs on a DC 48 V/0.7 A or DC 48 V/2 A adapter, draws 15.45 W or 7.2 W on average, and works between 0 and 40 °C. For AI-powered speaker and presenter tracking with a panoramic and PTZ dual-camera system, the Yealink UVC86 is the nearer fit.

Resolution
4K (maximum video output)
Type
Conference Camera Kit
  • 4K Video Output
  • Pan and Tilt Control
  • Zoom Lens
Price
On request · best price
1
Download spec sheet (PDF) Manufacturer datasheet (PDF)
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request

Key features

01
4K Video Output
Maximum video output resolution is 4K.
02
Pan and Tilt Control
Pan ±100° and tilt +30° and -90° cover the room.
03
Zoom Lens
Effective focal length of 3.4 mm to 40.4 mm, aperture F/1.8 to F/3.6.
04
White Balance Modes
Auto tracking, manual and one-push white balance.
05
CP50 Speakerphone Included
The kit includes the CP50 conference speakerphone.
06
Plug-and-Play BYOD
Designed for plug-and-play BYOD meetings.
07
Average Power Draw
Average power consumption of 15.45 W and 7.2 W.
08
Operating Range
Operates at 0 to 40 °C and 10% to 95% humidity, non-condensing.

Specifications

13 specifications
General
Key FeaturesPan ±100°, aperture F/1.8–F/3.6, auto tracking white balance, shutter 1/60–1/10000 s, CP50 speakerphone included, plug-and-play BYOD
ModelUVC85-BYOD
TypeConference Camera Kit
Display
Camera4K intelligent camera (UVC85)
Resolution4K (maximum video output)
ZoomEffective focal length f=3.4 mm to 40.4 mm
Performance
Storage Conditions-30 to 70 °C
Power
Power Consumption15.45 W / 7.2 W (average)
Power SourceDC 48 V / 0.7 A or DC 48 V / 2 A adapter
Physical
Dimensions200 x 151 x 125 mm
Operating Humidity10% to 95%, non-condensing
Operating Temperature0 to 40 °C
Tilt+30° / -90°

Downloads

Manufacturer documents for the Yealink UVC85 BYOD 4K Conference Camera Kit – UVC85-BYOD — datasheets, manuals, drawings and certificates.

Questions

Can’t find your answer? Ask on WhatsApp

Is the UVC85-BYOD suitable for medium and large meeting rooms?
Yes. Yealink describes the UVC85-BYOD as a professional audio and video conferencing kit for medium and large meeting rooms. It combines the UVC85 4K camera with the CP50 conference speakerphone, so one kit covers both the picture and the sound.
What zoom range does the UVC85 camera have?
The UVC85 has an effective focal length of f=3.4 mm to 40.4 mm and an aperture of F/1.8 to F/3.6. Pan is ±100° and tilt is +30° and -90°, so the camera can frame a wide room from one position without moving the unit.
How is the UVC85-BYOD powered?
The camera uses a DC 48 V/0.7 A or DC 48 V/2 A power adapter. Yealink lists USB external power and standard PoE as not supported for this model, so plan for the supplied adapter when you lay out cabling for the room.
How does the UVC85-BYOD compare with the UVC86?
The UVC85-BYOD is a camera and speakerphone kit with pan ±100° and tilt +30° and -90°. The UVC86 is a 4K dual-eye system with panoramic and PTZ cameras, and Yealink lists AI-powered speaker and presenter tracking and auto framing for it.
What operating and storage conditions apply to the UVC85?
The camera operates between 0 and 40 °C at 10% to 95% humidity, non-condensing. Yealink lists storage between -30 °C and 70 °C, so the unit can be kept in a store room or a cabinet between installations.
Can I buy the UVC85-BYOD in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
