VSYS VCM-M06 Motorised Swing TV Wall Mount for 32"–75" Displays, 50 kg
- Model: VCM-M06
- SKU: VCM-M06
Actual Stock & Price Can Be Confirmed After Placing the Order.
The VSYS VCM-M06 is a motorised swing wall mount for 32"–75" displays up to 50 kg, driven through 170 degrees of swivel by remote control, available in the UAE from Procure.ae. Manual articulating arms work well until the screen is heavy, the arm is... See More
The VSYS VCM-M06 is a motorised swing wall mount for 32"–75" displays up to 50 kg, driven through 170 degrees of swivel by remote control, available in the UAE from Procure.ae.
Manual articulating arms work well until the screen is heavy, the arm is long, or the person who needs to move it cannot easily reach it. A 65" panel on a full-extension arm takes two hands and a deliberate effort to reposition, and repeated handling marks the bezel. The VCM-M06 removes the handling entirely. The display is driven by a motor rather than pushed, which suits open-plan rooms where one screen has to serve a lounge, a dining table and a kitchen at different times of day.
Swing runs from 0 to 170 degrees and is commanded from the supplied RF remote, which does not need line of sight to the mount. Preferred angles can be stored in position memory and recalled with a single press, and a collision-avoidance system halts the movement if the arm meets an obstruction. Retracted depth is 56 mm, so the screen sits close to the wall when it is parked. The mount accepts VESA patterns from 200 x 200 mm to 600 x 400 mm and runs from a standard AC supply through the included 1.5 m power cord.
It is supplied to corporate, education, hospitality and government organisations across the UAE, with procurement-ready quotations and regional delivery.
Key Features
- Motorised swing through 0 to 170 degrees means the display is repositioned by remote rather than by hand.
- RF remote control is supplied, so the mount responds without needing to be pointed at directly.
- Position memory stores preferred viewing angles and recalls them in one press, which matters in rooms with fixed seating zones.
- Collision avoidance stops the swing when an obstruction is detected in the arm's path.
- Rated for 32" to 75" displays up to 50 kg, and load-tested to three times that rated capacity.
- Retracted depth of 56 mm keeps the screen close to the wall when the arm is parked.
- VESA coverage from 200 x 200 mm to 600 x 400 mm fits the mounting grids used across this size class.
- Runs from a standard AC outlet using the supplied 1.5 m power cord, with no separate control box to specify.
- Wall plate, fixing hardware and a hook-on bubble level are supplied for fixing to a solid wall or a stud.
- Useful in accessible installations where reaching behind or beside a manual mount is difficult.
Technical Specifications
| Model | VCM-M06 |
| Mount type | Motorised swing wall mount |
| Screen size range | 32 to 75 inches |
| Weight capacity | Up to 50 kg |
| Swivel | 0 to 170 degrees, motorised |
| Control | RF remote control with position memory |
| Safety | Collision-avoidance stop |
| Retracted depth | 56 mm |
| VESA range | 200 x 200 mm to 600 x 400 mm |
| Power | Standard AC supply, 1.5 m power cord included |
| Load testing | Tested to three times the rated capacity |
| Supplied with | Wall plate, hardware, hook-on bubble level and RF remote |
Ideal for: open-plan living and dining spaces, executive offices and small meeting rooms, retail displays that turn to face the shop floor, hotel suites and long-stay apartments, clinic and consultation rooms, and accessible installations where a manual arm is hard to reach, across Dubai, Abu Dhabi, Sharjah and the wider GCC.
| Name | VSYS VCM-M06 Motorised Swing TV Wall Mount for 32"–75" Displays, 50 kg |
| Mounting Type | Wall mount |
| Screen Size Support | 32 to 75 inches |
| Wall Mount Type | Motorised swing arm |
| Product Type | Motorised swing wall mount |
| Screen Size Range | 32 to 75 inches |
| Load Capacity | Up to 50 kg |
| VESA Compatibility | 200 x 200 mm to 600 x 400 mm |
| Movement | Motorised swing from 0 to 170 degrees with RF remote control |
| Swivel | 0 to 170 degrees, motorised |
| Wall Clearance | 56 mm when retracted |
| Mounting Interface | Solid wall or stud using the supplied wall plate and hardware |
| In the Box | Wall plate and hardware, RF remote control, hook-on bubble level and 1.5 m power cord |
| MPN | VCM-M06 |
| Model | VCM-M06 |
No datasheet available.
Frequently Asked Questions
Where can I buy the VSYS VCM-M06 in the UAE?
Procure.ae supplies the VSYS VCM-M06 across the UAE, with delivery to Dubai, Abu Dhabi, Sharjah and the wider GCC and procurement-ready quotations for project quantities.
Is the VCM-M06 a motorized mount or a manual one?
It is motorized. The swing is driven by a motor and commanded from the supplied RF remote control, so the display is not pushed into position by hand.
How far does the display swing?
From 0 to 170 degrees. That is enough to turn a screen from flat against the wall to facing well down the adjacent side of the room, which is what open-plan layouts usually need.
Can it remember my preferred viewing angles?
Yes. Position memory lets saved angles be recalled from the remote, so the screen returns to a set position rather than being nudged into place each time.
What happens if something is in the way when it swings?
A collision-avoidance system detects the obstruction and stops the movement, which protects both the panel and whatever is in the arm's path.
Does it need a special power supply?
No. It runs from a standard AC outlet using the 1.5 m power cord supplied, so plan for a socket within reach of the mount position when the wall is being prepared.
