SonyDigital SignageSKU FW-100BZ40J
Sony Pro BRAVIA BZ40J 100-inch 4K UHD Digital Signage Display – FW-100BZ40J
The Sony FW-100BZ40J is a 100-inch 4K UHD professional display from the Pro BRAVIA BZ40J series, built for digital signage in retail, hospitality and corporate spaces. It offers 3840 x 2160 resolution, 600 nits typical brightness and HDR10, HLG and Dolby Vision support. Procure.ae supplies the FW-100BZ40J in the UAE.
The FW-100BZ40J uses a 100-inch VA LCD panel with direct LED backlighting and local dimming. It delivers 600 nits typical and 940 nits peak brightness, a 9,000:1 native contrast ratio and a 178-degree viewing angle. It supports HDR10, HLG and Dolby Vision, with 4K X-Reality PRO video processing and a Cognitive Processor XR. The panel runs at 100 Hz or 120 Hz native refresh, and built-in 10 W + 10 W speakers add Dolby Atmos and Dolby Audio support.
The display suits signage networks that use IP control, RS-232C control, HDMI-CEC and TDM Digital Signage or TEOS compatibility. It supports Multicast/IPTV, Wi-Fi Direct, Apple AirPlay, Chromecast built-in and Google Play Store apps. It can be mounted in portrait mode on a 600 x 400 mm VESA pattern, and it weighs 88.9 kg without stand.
Screen Size
100 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
600 nits typical, 940 nits peak
Type
Digital Signage Display
- 4K UHD panel
- High brightness
- Local dimming
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
4K UHD panel
3840 x 2160 resolution on a 100-inch VA LCD panel with a 16:9 aspect ratio.
02
High brightness
600 nits typical and 940 nits peak brightness.
03
Local dimming
direct LED backlight with a 9,000:1 native contrast ratio.
04
HDR support
HDR10, HLG and Dolby Vision compatibility.
05
Dolby Atmos audio
10 W + 10 W speakers with Dolby Atmos and Dolby Audio support.
06
Signage management
compatible with TDM Digital Signage and TEOS solutions, with Multicast/IPTV support.
07
Wireless connectivity
integrated Wi-Fi, Wi-Fi Direct, Apple AirPlay and Chromecast built-in.
08
Control and inputs
IP control, RS-232C control, HDMI-CEC and four HDMI inputs.
Specifications
27 specificationsGeneral
Key FeaturesLocal dimming, HDR10 / HLG / Dolby Vision, Dolby Atmos, Portrait mode, Chromecast built-in, Apple AirPlay, TDM / TEOS compatible, IP control
ModelFW-100BZ40J
TypeDigital Signage Display
Display
Aspect Ratio16:9
BacklightDirect LED with local dimming
Brightness600 nits typical, 940 nits peak
Contrast Ratio9,000:1 native
Display TypeLCD
Panel TechnologyVA
Refresh Rate100 Hz / 120 Hz
Resolution3840 x 2160 (4K UHD)
Response Time7 ms
Screen Size100 inch
Viewing Angle178 degrees (89 / 89)
Performance
Duty Cycle24/7
Storage16 GB
Audio
Dynamic RangeHDR10, HLG, Dolby Vision
Speaker Output10 W + 10 W
Connectivity
Input Voltage220–240 V AC
PortsHDMI In × 4, USB × 2, Ethernet × 1, RS-232C × 1, Composite Video In × 1, Headphone Out × 1, Digital Audio Out × 1
Wi-FiIntegrated, with Wi-Fi Direct
Power
Standby Power0.50 W
Physical
ColorBlack
MountingVESA wall mount, portrait mode
VESA Mount600 x 400 mm
Weight88.9 kg (without stand)
Compliance
Warranty3 years
Downloads
Manufacturer documents for the Sony Pro BRAVIA BZ40J 100-inch 4K UHD Digital Signage Display – FW-100BZ40J — datasheets, manuals, drawings and certificates.
- Datasheet – FW-100BZ40J
- User manual – FW-100BZ40J
- User manual – Sony (covers 19 models)
- User manual – Sony BZ30J / BZ40J
- User manual – FW-100BZ40J
- User manual – FW-100BZ40J
- User manual – FW-100BZ40J
- BRAVIA-Wifi-Access-point-Meeting-Free-App EN
- BRAVIA-line-up-chart-2022-EU-WEB1
- Multi-screen-installation-of-LCD-Displays-or-LCD-Monitors
- BRAVIA Datasheet 2021
- Safety 50181151M
- Dismantling information for use by professional recyclers(English only) 98887924M
- FLYER, B2B INDIA 50347831M
- Safety 50181131M
Questions
Can’t find your answer? Ask on WhatsApp
Is the FW-100BZ40J built for 24/7 digital signage?
Yes. The manufacturer lists 24/7 operation for the FW-100BZ40J. It has a power saving mode, an on/off timer and 0.50 W standby consumption, and it includes a 3-year PrimeSupport warranty with repair or advanced exchange.
Can the FW-100BZ40J be wall mounted in portrait orientation?
Yes. The display supports portrait mode and is VESA hole spacing compatible with a 600 x 400 mm hole pitch. It weighs about 88.9 kg without stand, so use a wall mount rated for that weight and confirm the VESA pattern before installation. Procure.ae can arrange installation across the UAE.
Can the FW-100BZ40J be controlled from a central system?
Yes. It supports IP control and RS-232C control through a side-panel port, and HDMI-CEC lets compatible sources control the display over HDMI. It is also compatible with TDM Digital Signage and TEOS solutions, so it can run in a managed signage network.
Which video signals does it accept?
It has four HDMI inputs with HDCP 2.3 on each port. Supported signals include 4096 x 2160 and 3840 x 2160 at up to 60 Hz, and 1080p at up to 120 Hz, plus 720p and 480p formats. It also has one composite video input.
Does the FW-100BZ40J have built-in speakers and audio outputs?
Yes. It has 10 W + 10 W speakers with Dolby Atmos and Dolby Audio support. A headphone output and a digital audio output are on the side panel for external sound equipment, and HDMI ARC is supported.
