PanasonicMeeting Room SolutionsSKU ET-SBFMP10
Panasonic FMP50 Series Media Processor Function Board – ET-SBFMP10
The Panasonic ET-SBFMP10 is a media processor function board from the FMP50 Series for multi-projection installations. It outputs 4K UHD at 60p from a single output, connects through one LAN cable and supports NDI and Dante. Procure.ae supplies the ET-SBFMP10 across the UAE.
The ET-SBFMP10 handles warp and blend processing for multi-projection displays, with 4K media playback and playlist and schedule management in its included software. Camera-based auto calibration, which needs a separately sold compatible camera, handles blending and black-level adjustment. Its pixel-based screen adjustment is designed for precision compared with block or area-based methods. Signal input can reach 18 million pixels, with a maximum length of 7680 pixels, and the unit supports content interruption and picture-in-picture during scheduled playback.
Resolution
3840 x 2160 (4K UHD) at 60p, single...
Type
Media Processor
- 4K UHD output
- Single LAN connection
- Network AV support
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
4K UHD output
Outputs 3840 x 2160 at 60p from a single output.
02
Single LAN connection
The function board connects through one LAN cable.
03
Network AV support
Supports NDI (up to 3840 x 2160/60p) and Dante (2-channel).
04
Auto calibration
Camera-based calibration handles blending and black-level adjustment, with the camera sold separately.
05
No separate licence
Warp and blend, playlists and schedules work without a separate licence.
Specifications
8 specificationsGeneral
CompatibilitySelected Panasonic projectors, including PT-RQ45K/RZ45K, PT-RZ24K and PT-REQ15 series
Key FeaturesCamera-based auto calibration, Pixel-based screen adjustment, 4K media playback, Playlist and playback scheduling, Content interruption and PinP, Warp and blend software, No separate licence
ModelET-SBFMP10
TypeMedia Processor
Display
Resolution3840 x 2160 (4K UHD) at 60p, single output
Connectivity
EthernetSingle LAN cable connection
ProtocolsNDI, Dante (2-channel)
Physical
Form FactorFunction board (SDM board type)
Downloads
Manufacturer documents for the Panasonic FMP50 Series Media Processor Function Board – ET-SBFMP10 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Which Panasonic projectors is the ET-SBFMP10 compatible with?
The manufacturer lists the ET-SBFMP10 as compatible with projectors including the PT-RQ45K/RZ45K, PT-RQ25K, PT-RZ24K, PT-RQ18K and PT-REQ15/REQ15L. Send your exact projector model to Procure.ae to confirm matching before ordering, as the manufacturer lists only selected models.
What is the maximum output resolution?
The ET-SBFMP10 outputs up to 3840 x 2160 (4K UHD) at 60p from one output. It also supports 4K media playback, and its signal input can reach 18 million pixels with a maximum length of 7680 pixels.
Does the ET-SBFMP10 need a licence or extra software?
No. The manufacturer states that the FMP50 Series software handles warping, blending and playlists without a separate licence or additional licensing fees. Camera-based auto calibration needs a compatible camera, which is sold separately.
Can I buy the ET-SBFMP10 in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
