PanasonicMeeting Room SolutionsSKU TY-ST75PE9
Panasonic Display Pedestal – TY-ST75PE9
The Panasonic TY-ST75PE9 is a display pedestal supplied as two bases and two pedestal tubes, each piece measuring 112 x 828 x 540 mm. It weighs approximately 5.5 kg and includes M6 display screws and overturn-prevention parts. Procure.ae, an authorised reseller, supplies it in the UAE and can confirm which Panasonic display it suits.
The pedestal comes as two bases and two pedestal tubes. One pedestal piece measures 112 x 828 x 540 mm (W x H x D) and the weight is approximately 5.5 kg. The bases are fixed with four M4 x 28 assembly screws, and the display is attached with four M6 x 41 display screws. Overturn-prevention parts are included: two bands, two M4 x 15 screws and two wood screws. The carton measures 892 x 215 x 414 mm and weighs approximately 9 kg gross.
Panasonic's installation instructions for the TY-ST75PE9 call for a stable, level surface and for at least 10 cm of space above and beside the display and 5 cm behind it. Two or more people are required when the display weighs more than 25 kg, and four when it weighs more than 50 kg. The manufacturer's specifications do not name compatible display models, so Procure.ae confirms fit before supply.
Type
Display Pedestal
Weight
5.5 kg
- Two bases and tubes
- Display screws included
- Overturn prevention
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Two bases and tubes
The pedestal is supplied as 2 bases and 2 pedestal tubes, assembled with four M4 x 28 screws.
02
Display screws included
Four M6 x 41 screws attach the display to the pedestal.
03
Overturn prevention
Two bands, two M4 x 15 screws and two wood screws are supplied to secure the display.
04
Tube height
Each pedestal piece is 828 mm tall, 112 mm wide and 540 mm deep.
05
Weight
Approximately 5.5 kg for the pedestal, or about 9 kg gross when packed.
06
Handling guidance
Two or more people are needed above 25 kg display weight, and four above 50 kg.
Specifications
8 specificationsGeneral
Key FeaturesTwo bases and tubes, M6 display screws included, overturn-prevention parts, 828 mm tall, 5.5 kg
ModelTY-ST75PE9
TypeDisplay Pedestal
What's in the BoxBases × 2, pedestal tubes × 2, screws M4 x 28 × 4, display screws M6 x 41 × 4, bands × 2, screws M4 x 15 × 2, wood screws × 2
Physical
Dimensions112 x 828 x 540 mm (per pedestal piece)
Shipping Dimensions892 x 215 x 414 mm
Shipping Weight9 kg
Weight5.5 kg
Downloads
Manufacturer documents for the Panasonic Display Pedestal – TY-ST75PE9 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Which displays does the Panasonic TY-ST75PE9 fit?
The manufacturer's specification sheet does not list compatible display models. Its instructions state that displays other than those given in Panasonic's catalogue must not be used with the pedestal. Procure.ae can confirm whether your Panasonic display suits the TY-ST75PE9 before you order.
What parts are supplied with the TY-ST75PE9?
The pedestal includes two bases, two pedestal tubes, four M4 x 28 assembly screws for the pedestal and four M6 x 41 screws for the display. Overturn-prevention parts are two bands, two M4 x 15 screws and two wood screws.
What are the size and weight of the TY-ST75PE9?
One pedestal piece measures 112 x 828 x 540 mm (W x H x D). The pedestal weighs approximately 5.5 kg. The carton measures 892 x 215 x 414 mm and weighs approximately 9 kg gross, so use enough people when handling the pedestal and display.
How many people are needed to install a display on the TY-ST75PE9?
Panasonic requires two or more people when the display weighs more than 25 kg, and four people when it weighs more than 50 kg. Also use the overturn-prevention parts, tighten all screws, and keep 10 cm free above and beside the display and 5 cm behind it.
