NECInteractive Flat PanelsSKU V554Q PCAP
NEC MultiSync 55-inch 4K PCAP Touch Interactive Flat Panel – V554Q PCAP
The NEC MultiSync V554Q PCAP is a 55-inch 4K UHD interactive display with projected capacitive (PCAP) touch for up to 80 simultaneous touches and an edge-to-edge glass front. It is designed for table installations and offers an OPS slot and 24/7 operation. Procure.ae supplies it across the UAE for retail, hospitality and exhibition use.
The NEC MultiSync V554Q PCAP (PCAP touch) has a 3840 x 2160 native resolution on a 55-inch screen. Projected capacitive touch handles up to 80 touches with a finger or thin gloves, with accuracy below 1 mm. The glass front is flush with no bezel. It is an IPS panel with edge LED backlights rated at 500 nits with a 1,100:1 typical contrast ratio and 178°/178° viewing angles. Integrated 10 W + 10 W speakers plus ambient light, temperature and NFC sensors are built in.
The V554Q PCAP is part of the NEC MultiSync V Series. Unlike the InGlass and ShadowSense versions, it is built for flat, face-up table installations as well as upright use, with table legs, a wooden surround and a PC holder listed as accessories. It supports native multi-touch on Windows 7 to 11, Linux and Android, and mounts on a 300 x 300 mm FDMI pattern (M6). It weighs 42.5 kg.
Screen Size
55 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Touch Technology
PCAP
- PCAP touch
- 4K UHD panel
- Wide connectivity
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
PCAP touch
Projected capacitive touch recognises up to 80 touches from a finger or thin gloves.
02
4K UHD panel
IPS panel with edge LED backlights, 3840 x 2160 resolution and 1,100:1 typical contrast.
03
Wide connectivity
Three HDMI and two DisplayPort inputs with HDCP, plus a DisplayPort loop-through output.
04
OPS and Compute Module
An OPS slot and a NEC Compute Module 3 slot accept embedded PCs and Raspberry Pi Compute Module 1 and 3.
05
Built-in sensors
Ambient light and temperature sensors are integrated, with triggered actions programmable. An NFC sensor works with a free NEC Android app.
06
Integrated audio
10 W + 10 W integrated speakers, with optional 15 W + 15 W speakers and a soundbar available as accessories.
07
24/7 operation
Specified for 24/7 operation at 0 to 35 °C and 20% to 80% humidity, with IP5x front protection.
08
Table-ready design
Face-up orientation is supported, with table legs, a wooden surround and a PC holder listed as accessories.
Specifications
43 specificationsGeneral
CompatibilityNative multi-touch: Windows 7–11, Linux, Android; mouse mode: Windows XP, Windows Vista, macOS
Key Features4K UHD, PCAP touch, 80 touches, edge-to-edge glass, table installation, OPS slot, Compute Module slot, 24/7 operation
ModelV554Q PCAP
TypeInteractive Flat Panel
What's in the BoxDisplay, DisplayPort cable, HDMI cable, power cable, remote control, user manual
Display
Aspect Ratio16:9
BacklightEdge LED
Bezel SizeEdge-to-edge flush glass (no bezel)
Brightness500 nits
Color Depth1.073 billion colours (10-bit)
Contrast Ratio1,100:1
OrientationLandscape, portrait, face up
Panel TechnologyIPS
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response Time8 ms (grey-to-grey)
Screen Size55 inch
Touch Accuracy< 1 mm
Touch Points80-point multi-touch
Touch TechnologyPCAP
Viewing Angle178° horizontal / 178° vertical
Audio
Audio In3.5 mm jack × 1
Audio Out3.5 mm jack × 1
DisplayPortDisplayPort In × 2 (HDCP), DisplayPort Out × 1 (loop-through)
Speaker Output10 W + 10 W (integrated)
Connectivity
Ethernet100 Mbit LAN In × 1, LAN Out × 1
ExpansionNEC Compute Module 3 slot (NEC Compute Module, Raspberry Pi Compute Module 1 and 3)
HDMI InputsHDMI In × 3 (HDCP)
InputsHDMI × 3, DisplayPort × 2, OPS slot, 3.5 mm audio, LAN, RS-232, USB Type-B (touch)
OPS SlotOPS slot (NEC / Intel Open Pluggable Specification)
Serial PortRS-232 × 1
Touch USB PortsUSB Type-B × 1 (upstream, USB-HID)
USB PortsUSB 2.0 × 1 (downstream), USB 2.0 × 1 (media player), USB 2.0 × 2 (compute module)
Power
Power Consumption132 W (Eco, shipment setting)
Standby Power< 0.5 W; < 2 W (networked standby)
Physical
Dimensions1279 x 749 x 75.9 mm
Duty Cycle24/7
Operating Humidity20% to 80% RH
Operating Temperature0 to 35 °C
VESA Mount300 x 300 mm (FDMI), M6
Weight42.5 kg
Compliance
CertificationsCE, EAC, EMC Class B, REACH, RoHS
IP RatingIP5x (front), IP2x (back)
Downloads
Manufacturer documents for the NEC MultiSync 55-inch 4K PCAP Touch Interactive Flat Panel – V554Q PCAP — datasheets, manuals, drawings and certificates.
- Datasheet – MultiSync V Series – V554Q PCAP Datasheet
- User manual – MultiSync V Series – NEC V554Q CD EN V01
- User manual – MultiSync V Series – NEC V554Q CD SA V01
- User manual – MultiSync V Series – NEC V554Q Setup Manual SA V01
- User manual – MultiSync V Series – V554Q Setup Manual EN V01
- Brochure – NEC (covers 64 models)
- Brochure – NEC (covers 96 models)
Questions
Can’t find your answer? Ask on WhatsApp
How many touch points does the NEC MultiSync V554Q PCAP support?
Yes, it is a true multi-touch display. The V554Q PCAP uses projected capacitive (PCAP) touch and recognises up to 80 simultaneous touches from a finger or thin gloves. Touch accuracy is under 1 mm and the connection to the host PC is USB-HID.
Which video inputs and ports does the NEC MultiSync V554Q PCAP have?
It has three HDMI inputs and two DisplayPort inputs, all with HDCP, plus a DisplayPort loop-through output. Audio connects through a 3.5 mm jack, control through 100 Mbit LAN, RS-232 and a remote-control wire, and touch through a USB Type-B upstream port.
Can I fit a PC or compute module inside the NEC MultiSync V554Q PCAP?
Yes. The OPS slot (NEC / Intel Open Pluggable Specification) accepts an HDBaseT receiver or an Intel Atom, Celeron or Core CPU module. A separate NEC Compute Module 3 slot takes the NEC Compute Module or Raspberry Pi Compute Module 1 and 3.
Can the NEC MultiSync V554Q PCAP be installed flat as a table?
Yes. The manufacturer designs the PCAP version for table installations, supports face-up orientation and lists table legs, a wooden surround and a PC holder as accessories. It can also be wall-mounted on the 300 x 300 mm FDMI pattern (M6), and it weighs 42.5 kg.
Can the NEC MultiSync V554Q PCAP run all day?
Yes, the manufacturer specifies 24/7 operation. The operating range is 0 to 35 °C and 20% to 80% humidity, and the front has IP5x protection. Power use is 132 W in the Eco shipment setting.
