LGDigital SignageSKU 86BH5F
LG Ultra Stretch Signage 86-inch Digital Signage Display – 86BH5F
The LG 86BH5F is an 86-inch ultra-stretch signage display with a 58:9 aspect ratio for wide, low-profile installations. It offers 3840 x 600 resolution, 500 nits typical brightness and tile mode for video walls of up to 15 x 15 units. Procure.ae supplies the LG 86BH5F across the UAE.
The 86BH5F uses an IPS panel with 3840 x 600 resolution, 500 nits typical brightness, a 1,100:1 contrast ratio and a 60 Hz refresh rate. Its 10-bit colour depth gives 1.07 billion colours, with a 178° x 178° viewing angle and an 8 ms response time. The 10% haze surface treatment and 24/7 rating support continuous use in portrait or landscape orientation. Alternate codes 86BH5F-B.AMA and 86BH5F-B.AMN are also listed.
Use the 86BH5F in wide corridors, transit platforms, retail walls and lobbies, or build a video wall with tile mode, which supports up to 15 x 15 units. It offers picture by picture (PBP) for four-screen layouts and integrates through RS232C, RJ45 LAN, IR, SNMP, Wake on LAN, HDMI-CEC and Crestron Inside. Content tools include SuperSign Control and Control+, SuperSign WB, SuperSign Media Editor and LG ConnectedCare. Mounting uses a 600 x 200 mm VESA interface for the 20.5 kg head.
Screen Size
86 inch
Resolution
3840 x 600
Brightness
500 nits
Type
Stretched Digital Signage Display
- Ultra-wide format
- Brightness and contrast
- Colour depth
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Ultra-wide format
58:9 aspect ratio on an 86-inch IPS panel with 3840 x 600 resolution.
02
Brightness and contrast
500 nits typical brightness with a 1,100:1 contrast ratio.
03
Colour depth
10-bit colour depth with 1.07 billion colours and NTSC 72% gamut.
04
Tile mode
Video wall tile mode supports up to 15 x 15 units.
05
Multi-screen layouts
Picture by picture (PBP) supports up to four screens.
06
Embedded CMS tools
Local content scheduling, group manager, USB plug and play and fail over.
07
Sensors and power saving
Auto brightness, temperature and current sensors, with Smart Energy Saving and PM mode.
08
Control and integration
RS232C, RJ45 LAN, IR, SNMP, Wake on LAN, HDMI-CEC, Beacon and Crestron Inside.
Specifications
32 specificationsGeneral
Key FeaturesTile mode up to 15 x 15, four-screen PBP, Crestron Inside, Wake on LAN, HDMI-CEC, SNMP, Beacon, auto brightness and temperature sensors, OPS piggyback compatible
Model86BH5F
TypeStretched Digital Signage Display
What's in the BoxRemote controller (2 batteries), power cord, DP cable, RS-232C cable, IR/light sensor receiver, manual
Display
Aspect Ratio58:9
Bezel SizeT/R/L/B 5.9 / 4.4 / 4.4 / 5.9 mm
Brightness500 nits
Color Depth10-bit (1.07 billion colours)
Color GamutNTSC 72%
Contrast Ratio1,100:1
OrientationPortrait and landscape
Panel TechnologyIPS
Refresh Rate60 Hz
Resolution3840 x 600
Response Time8 ms
Screen Size86 inch
Viewing Angle178° x 178°
Performance
Duty Cycle24/7
Operating SystemwebOS 4.0
Storage8 GB
Audio
Dynamic Range500,000:1 (dynamic contrast)
Connectivity
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 3, DisplayPort In × 1, DVI-D In × 1, Audio In/Out, RS232C In/Out, RJ45 (LAN) In/Out, USB 2.0 × 2, IR In, DP Out × 1
Wi-FiBuilt-in
Physical
ColorBlack
Dimensions2158.3 x 348.5 x 81.7 mm
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
Surface ProtectionHaze 10%
VESA Mount600 x 200 mm
Weight20.5 kg
Compliance
CertificationsCB / NRTL, FCC Class A, CE, KC
Downloads
Manufacturer documents for the LG Ultra Stretch Signage 86-inch Digital Signage Display – 86BH5F — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Is the LG 86BH5F suitable for 24/7 digital signage?
Yes. The manufacturer lists 24/7 operation, a 0 to 40 °C operating temperature range and 10% to 80% humidity. The panel has an 8 ms response time, and the unit supports Smart Energy Saving and PM mode.
What resolution and format does the 86BH5F use?
It uses a 58:9 aspect ratio with 3840 x 600 resolution on an 86-inch IPS panel. This wide format suits horizontal content such as corridor signage and ticker-style layouts, so check the space against the 2158.3 mm overall width before ordering.
What mounting does the 86BH5F need?
It uses a 600 x 200 mm VESA standard mount interface. The unit measures 2158.3 x 348.5 x 81.7 mm and weighs 20.5 kg, so the bracket must be rated for that load and the wall or ceiling must be checked. Procure.ae can advise on installation across the UAE.
Can it run in a video wall?
Yes. Tile mode supports up to 15 x 15 units, and the manufacturer lists RS232C sync and local network sync for multi-unit setups. Confirm the layout and cabling with your integrator before installation.
