LGDigital SignageSKU 98UH5Q-H
LG UHD Signage 98-inch Digital Signage Display – 98UH5Q-H
The LG 98UH5Q-H is a 98-inch 4K UHD digital signage display built for continuous commercial use. It offers 3840 x 2160 resolution, 500 nits typical brightness and webOS 6.1 with built-in content scheduling. Procure.ae supplies the LG 98UH5Q-H across the UAE.
The 98UH5Q-H uses a 98-inch ADS panel with direct backlight, 3840 x 2160 UHD resolution, 500 nits typical brightness and a 1,200:1 contrast ratio. Its 178° x 178° viewing angle, 1.07 billion colours and BT.709 95% colour gamut suit detailed content seen from wide angles. The 8 ms response time at 60 Hz, 24/7 operating rating and portrait or landscape orientation make it practical for always-on screens. Built-in Wi-Fi, two 10 W speakers and 8 GB of eMMC storage are included.
Use the 98UH5Q-H in lobbies, retail floors, corporate reception areas and wayfinding, or in video walls, since tile mode and RS232C sync support multi-screen setups. It runs webOS 6.1 with SuperSign CMS, SuperSign Control+, SuperSign Cloud and Mobile CMS, and integrates with control systems through RS232C, RJ45 LAN, SNMP, Wake on LAN, HDMI-CEC and Crestron Connected. The 800 x 400 mm VESA interface and 53.6 kg head weight mean the wall or frame must be rated for that load.
Screen Size
98 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Type
Digital Signage Display
- 4K UHD panel
- Brightness and contrast
- Wide viewing angle
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
4K UHD panel
3840 x 2160 resolution on a 98-inch ADS panel with direct backlight.
02
Brightness and contrast
500 nits typical brightness with a 1,200:1 contrast ratio.
03
Wide viewing angle
178° x 178° viewing angle with 1.07 billion colours and BT.709 95% gamut.
04
24/7 operation
Rated for continuous use, with an 8 ms response time at 60 Hz.
05
webOS signage platform
webOS 6.1 with 8 GB of eMMC storage.
06
Embedded content tools
Local content scheduling, video tags, play via URL and screen rotation.
07
Control and integration
RS232C, RJ45 LAN, HDMI-CEC, SNMP, Crestron Connected and Cisco certification.
08
Built-in connectivity
Wi-Fi and Bluetooth, auto brightness and temperature sensors, and two 10 W speakers.
Specifications
34 specificationsGeneral
Key FeaturesVideo tag, tile mode, local content scheduling, screen rotation, Crestron Connected, Cisco certified, auto brightness sensor, HDMI-CEC
Model98UH5Q-H
TypeDigital Signage Display
What's in the BoxRemote controller (2 batteries), power cord, regulation book, quick setup guide, warranty card, phone to D-Sub 9 adapter
Display
Aspect Ratio16:9
BacklightDirect
Bezel Size18 mm (even)
Brightness500 nits
Color Depth1.07 billion colours
Color GamutBT.709 95%
Contrast Ratio1,200:1
OrientationPortrait and landscape
Panel TechnologyADS
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size98 inch
Viewing Angle178° x 178°
Performance
Duty Cycle24/7
Operating SystemwebOS 6.1
Storage8 GB (eMMC)
Audio
Speaker Output10 W x 2 (built-in)
Connectivity
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 3, RJ45 (LAN) In × 1, RS232C In/Out, USB 2.0 × 2, Audio Out
Wi-FiBuilt-in
Power
Power Consumption200 W (smart energy saving mode)
Standby Power0.5 W
Physical
ColorBlack
Dimensions2190 x 1255 x 68.6 mm
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
VESA Mount800 x 400 mm
Weight53.6 kg
Compliance
CertificationsCB / NRTL, FCC Class B, CE, KC
Downloads
Manufacturer documents for the LG UHD Signage 98-inch Digital Signage Display – 98UH5Q-H — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Is the LG 98UH5Q-H rated for 24/7 digital signage?
Yes. The manufacturer lists 24/7 operation, an operating temperature of 0 to 40 °C and 10% to 80% humidity. Its Smart Energy Saving mode reduces power use to 200 W, and the panel has an 8 ms response time at 60 Hz.
What mounting does the 98UH5Q-H need?
It uses an 800 x 400 mm VESA standard mount interface. The display measures 2190 x 1255 x 68.6 mm and weighs 53.6 kg, so the wall bracket or frame must be rated for that load. Procure.ae can advise on mounting and installation across the UAE.
Can the 98UH5Q-H run in portrait orientation?
Yes. The manufacturer lists portrait and landscape orientation, with screen rotation and external input rotation settings. Tile mode can also join several units into a video wall, which suits menu boards and wayfinding.
Which content management software does it support?
It works with LG SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud and Mobile CMS. Local content scheduling, video tags and play via URL are also built in, and the manufacturer lists Connected Care for remote monitoring.
Does it integrate with building or control systems?
Yes. The manufacturer lists RS232C control and sync, RJ45 LAN control, SNMP, Wake on LAN, HDMI-CEC and Crestron Connected support, plus Cisco certification. Confirm the control protocol with your integrator before final installation.
Can I buy the 98UH5Q-H in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
