LGDigital SignageSKU 65UH5N-E
LG UH5N 65-inch UHD Digital Signage Display – 65UH5N-E
The LG 65UH5N-E is a discontinued 65-inch UHD digital signage display with an IPS panel, 500 nits typical brightness and webOS 6.0. It supported HDMI daisy-chaining and 24/7 operation for lobby, retail and corporate screens. Procure.ae can confirm current UAE availability or recommend the current successor model.
The panel provides 3840 x 2160 UHD resolution at 60 Hz, 500 nits typical brightness and a 1,100:1 contrast ratio. Its 10-bit colour depth and BT709 95% colour gamut support accurate playback of video and graphics. The display lists a 178 x 178 degree viewing angle, response times of 8 ms (rise) and 10 ms (fall), and 16 GB of internal memory. It operates 24/7 and supports both portrait and landscape orientation.
The LG 65UH5N-E runs webOS 6.0 with SuperSign CMS, group management and local content scheduling. Its HDMI and DisplayPort inputs with HDMI output allow daisy-chaining to the next display, which suits linked installations. Crestron connectivity, SNMP, RS-232C control and Wake on LAN support network management. Mount it on the 300 x 300 mm VESA interface and check the tilt limits stated for the model before installation.
Screen Size
65 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits (typical)
Type
Digital Signage Display
- UHD signage panel
- Daisy chain
- webOS 6.0 platform
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
UHD signage panel
3840 x 2160 IPS panel at 60 Hz with 500 nits typical brightness.
02
Daisy chain
Accepts HDMI and DisplayPort input and passes HDMI output to the next display.
03
webOS 6.0 platform
Built-in Wi-Fi, webRTC and Pro:Idiom support with 16 GB of internal memory.
04
Content scheduling
Local content scheduling, group manager and PBP for up to 4 screens.
05
Remote management
SNMP, Crestron connectivity, RS-232C control and Wake on LAN.
06
Built-in sensors
Temperature, auto brightness (IR) and gyro sensors.
07
Built-in speaker
Integrated audio output for signage content.
08
Energy control
Smart Energy Saving mode and 0.5 W power-off consumption.
Specifications
31 specificationsGeneral
Key FeatureswebOS 6.0, built-in Wi-Fi, daisy chain, SuperSign CMS, PBP up to 4 screens, tile mode up to 15 x 15, Crestron connectivity, SNMP
Model65UH5N-E
TypeDigital Signage Display
What's in the BoxRemote controller with 2 batteries, power cord, quick setup guide, regulation book, phone to RS-232C gender adapter, cable holders
Display
Aspect Ratio16:9
Bezel Size8.9 mm sides and top, 12.9 mm bottom
Brightness500 nits (typical)
Color Depth10-bit, 1.07 billion colors
Color GamutBT709 95%
Contrast Ratio1,100:1
Panel TechnologyIPS
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response TimeRise 8 ms / fall 10 ms
Screen Size65 inch
Viewing Angle178 x 178 degrees
Performance
Operating SystemwebOS 6.0
Storage16 GB
Connectivity
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 3, DisplayPort In × 1, USB 2.0 × 1, RS-232C In/Out, RJ-45 LAN, IR In, Audio Out × 1, HDMI Out × 1
Wi-FiBuilt-in
Power
Power Consumption145 W (typical), 200 W (maximum)
Physical
Dimensions1450.3 x 830.3 x 29.7 mm (W x H x D, without IR module)
Duty Cycle24/7
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
TiltFace-down up to 30°
VESA Mount300 x 300 mm
Weight24.2 kg (head only)
Compliance
CertificationsCB / NRTL, FCC Class B, CE, KC, ErP, Energy Star, ePEAT (US)
IP RatingIP5X
Questions
Can’t find your answer? Ask on WhatsApp
What are the screen size and resolution of the LG 65UH5N-E?
The LG 65UH5N-E has a 65-inch IPS screen with a native resolution of 3840 x 2160 (UHD) at 60 Hz. It uses a 16:9 aspect ratio and supports portrait and landscape orientation. The panel lists 500 nits typical brightness and a 1,100:1 contrast ratio, with edge backlighting.
Does the 65UH5N-E support daisy chaining?
Yes. The display accepts HDMI and DisplayPort input and outputs HDMI to the next display in a chain. The manufacturer lists the HDMI output at 3840 x 2160 at 30 Hz, so check the source and cable requirements for linked screens.
Is the 65UH5N-E compatible with Crestron and SNMP management?
Yes. The manufacturer lists Crestron connectivity, SNMP, RS-232C control, RJ-45 LAN control and Wake on LAN. These options let facilities teams monitor and control displays over a network, subject to the integrator's control system.
How is the 65UH5N-E mounted?
The display uses a 300 x 300 mm VESA interface. The monitor measures 1450.3 x 830.3 x 29.7 mm without the IR module, and the manufacturer lists a face-down tilt of up to 30 degrees at stated temperatures. Confirm the bracket and wall details with Procure.ae before installation.
What operating conditions does the 65UH5N-E support?
The manufacturer lists an operating temperature of 0 to 40 °C and humidity of 10% to 80%, with 24/7 operation. The IP5X rating covers dust protection. It runs on 100–240 V AC at 50/60 Hz, with typical consumption of 145 W and maximum consumption of 200 W.
Can I buy the 65UH5N-E in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
