LGDigital SignageSKU 55UL5Q-M
LG 55-inch UHD Digital Signage Display – 55UL5Q-M
The LG 55UL5Q-M is a 55-inch 4K UHD digital signage display with 500 nits of typical brightness, webOS 6.1 and 24/7 operation. It suits corporate lobbies, retail floors and hospitality screens, and it runs in portrait or landscape. Procure.ae supplies the LG 55UL5Q-M in the UAE.
The 55UL5Q-M (also listed as 55UL5Q-M.AMAQ) has a 3840 x 2160 (4K UHD) resolution on a 55-inch ADS panel. Typical brightness is 500 nits, the contrast ratio is 1,200:1 and the dynamic contrast ratio is 1,000,000:1. The screen covers 80% DCI colour gamut with 1.07 billion colours, an 8 ms response time at 60 Hz, and viewing angles of 178 degrees horizontal and vertical. It is rated for 24/7 operation.
The display runs webOS 6.1 with 8 GB of eMMC storage, and local content scheduling, group management and Play via URL are built in. It has three HDMI inputs, RS232C in and out, an RJ45 LAN port and two USB 2.0 ports, with built-in Wi-Fi and Bluetooth. Tile Mode Setting is listed for video wall layouts, and Crestron Connected and SuperSign CMS support centralised management. It mounts on a 300 x 300 mm VESA interface.
Screen Size
55 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Type
UHD Digital Signage Display
- 4K UHD panel
- webOS 6.1 platform
- Portrait and landscape
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
4K UHD panel
3840 x 2160 resolution on a 55-inch ADS panel rated at 500 nits typical.
02
webOS 6.1 platform
webOS 6.1 with 8 GB of eMMC storage for local content playback.
03
Portrait and landscape
Rotates between portrait and landscape for menu boards and wayfinding.
04
Wide viewing angle
178 degrees horizontal and 178 degrees vertical viewing angles.
05
24/7 operation
Rated for round-the-clock operation with a 1,000,000:1 dynamic contrast ratio.
06
Built-in Wi-Fi and Bluetooth
Wi-Fi and Bluetooth are built in, with an RJ45 LAN port for wired networks.
07
Central management
Supports SuperSign CMS, Crestron Connected and Control Manager.
08
Auto brightness sensor
An auto brightness sensor adjusts the screen to ambient light.
Specifications
33 specificationsGeneral
Key Features4K UHD ADS panel, webOS 6.1, Portrait and landscape, Built-in Wi-Fi and Bluetooth, Crestron Connected, SuperSign CMS, Auto brightness sensor, 24/7 operation
Model55UL5Q-M
TypeUHD Digital Signage Display
What's in the BoxRemote controller (2 batteries), power cord, quick start guide, regulation book, phone to RS232C adapter
Display
Aspect Ratio16:9
Bezel Size10.8 mm (even bezel)
Brightness500 nits
Color Depth1.07 billion colours
Color GamutDCI 80%
Contrast Ratio1,200:1
OrientationPortrait and landscape
Panel TechnologyADS
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size55 inch
Viewing Angle178° (H) / 178° (V)
Performance
Operating SystemwebOS 6.1
Storage8 GB eMMC
Audio
Speaker Output10 W × 2
Connectivity
ConnectivityBuilt-in Wi-Fi and Bluetooth; RJ45 LAN
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 3, RS232C In × 1, RS232C Out × 1, RJ45 LAN × 1, USB 2.0 × 2, Audio Out × 1
Power
Standby Power0.5 W (power off)
Physical
ColorBlack
Dimensions1234.2 x 706.5 x 58.9 mm
Duty Cycle24/7
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
Tilt15° face up / 15° face down
VESA Mount300 x 300 mm
Weight14 kg
Compliance
CertificationsCB, FCC Class B, CE
Downloads
Manufacturer documents for the LG 55-inch UHD Digital Signage Display – 55UL5Q-M — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What resolution and brightness does the LG 55UL5Q-M have?
It has a 3840 x 2160 (4K UHD) resolution and 500 nits of typical brightness on a 55-inch ADS panel. The contrast ratio is 1,200:1, the dynamic contrast ratio is 1,000,000:1, and the display is rated for 24/7 operation.
Can the LG 55UL5Q-M be mounted in portrait orientation?
Yes. The display supports both portrait and landscape orientation and has a 300 x 300 mm VESA mount interface. The manufacturer's specifications do not state a bracket model, so confirm the mount with Procure.ae before installation.
Does the LG 55UL5Q-M work with SuperSign CMS or Crestron?
Yes. The manufacturer lists SuperSign CMS, SuperSign Control+, SuperSign WB, Mobile CMS and Crestron Connected support. It also has RS232C in and out, RJ45 LAN, SNMP and Wake on LAN for control and monitoring from AV or building systems.
What operating system and storage does the LG 55UL5Q-M use?
It runs webOS 6.1 with 8 GB of internal eMMC storage. Local content scheduling, Screen Share, Video Tag and Gapless Playback are listed as built-in features for playing content from the display itself.
