InFocusInteractive Flat PanelsSKU INF5522AG
InFocus INF5522AG 55-inch Interactive Flat Panel with Built-in Android PC
The InFocus INF5522AG is a 55-inch interactive flat panel with a built-in Android PC, four HDMI inputs, VGA, an HDMI output and RS-232 control. A bay on the back accepts an optional PC, and the hardware guide covers camera mounting. Procure.ae supplies it in the UAE.
The INF5522AG pairs a 55-inch touch display with an internal Android PC that has its own LAN port plus USB 2.0 and USB 3.0 ports. External sources connect through HDMI 1 to 3, HDMI 4 (which supports HDMI 2.0, HDCP 2.2 and MHL), VGA with a 3.5 mm PC audio input, composite AV-In and component Y/Pb/Pr. A Touch USB Type-B port links the panel to a computer for touch control.
The HDMI Out port mirrors HDMI inputs 1 to 3 to a second display, and audio leaves through SPDIF, a 3.5 mm headset jack or composite AV-Out. RS-232 in and out ports support control systems, and the panel is operated with a remote control or front keypad. Compared with the INF5512AG guide, the INF5522AG guide adds instructions for mounting a camera on the display.
Screen Size
55 inch
Type
Interactive Flat Panel with Built-i...
- 55-inch display
- Built-in Android PC
- Four HDMI inputs
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
55-inch display
A 55-inch diagonal panel mounted with M6 screws on suitably rated hardware.
02
Built-in Android PC
An internal Android PC has its own RJ45 LAN, USB 2.0 and two USB 3.0 ports.
03
Four HDMI inputs
HDMI 1 to 3 plus HDMI 4, which supports HDMI 2.0, HDCP 2.2 and MHL.
04
HDMI output
HDMI Out mirrors the display to a second screen from HDMI inputs 1 to 3.
05
Computer inputs
VGA with a 3.5 mm PC audio input, plus composite and component (Y/Pb/Pr) video.
06
Optional PC bay
A bay on the back of the panel holds an optional PC, with a dedicated OPS PC USB port.
07
Camera mounting
The hardware guide includes a procedure for mounting a camera on the display.
08
RS-232 control
RS-232 In and RS-232 Out ports support remote control applications.
Specifications
17 specificationsGeneral
ControlsRemote control, front keypad, RS-232 In/Out
Key Features55-inch panel, built-in Android PC, four HDMI inputs, HDMI Out, VGA, OPS PC bay, SPDIF out, RS-232 In/Out, camera mounting
ModelINF5522AG
TypeInteractive Flat Panel with Built-in Android PC
Display
Screen Size55 inch
Performance
Operating SystemAndroid (built-in PC)
Audio
Audio InRCA L/R × 1, 3.5 mm PC audio × 1
Audio OutSPDIF × 1, 3.5 mm headset × 1, composite AV-Out × 1
Connectivity
EthernetRJ45 LAN × 1 (for the Android PC)
HDMI InputsHDMI × 4 (HDMI 4 supports HDMI 2.0 / HDCP 2.2 and MHL)
HDMI OutputsHDMI Out × 1 (mirrors HDMI 1 to 3)
InputsHDMI × 4, VGA × 1, composite AV-In × 1, component Y/Pb/Pr × 1, RCA L/R audio × 1, PC audio 3.5 mm × 1
OPS SlotOptional PC bay on back of panel (OPS PC USB port)
Serial PortRS-232 In × 1, RS-232 Out × 1
USB PortsUSB 2.0 × 1, USB 3.0 × 2 (to Android PC), Touch USB Type-B × 1, OPS PC USB × 1
VGA InputVGA × 1
Physical
MountingWall or stand mounting with M6 screws
Downloads
Manufacturer documents for the InFocus INF5522AG 55-inch Interactive Flat Panel with Built-in Android PC — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What size is the InFocus INF5522AG?
The hardware guide refers to a 55-inch diagonal display when giving its M6 mounting screw requirement, so the INF5522AG is a 55-inch interactive flat panel. The guide does not list resolution or brightness, so ask Procure.ae if you need those figures confirmed.
Does the INF5522AG have a built-in computer?
Yes. It has an internal Android PC with its own LAN (RJ45) port, one USB 2.0 port and two USB 3.0 ports. The guide also describes an optional PC that fits in the bay on the back of the panel, connected through the OPS PC USB port.
Which video inputs does the INF5522AG have?
It has four HDMI inputs, with HDMI 4 supporting HDMI 2.0, HDCP 2.2 and MHL, plus VGA with a 3.5 mm PC audio input, composite AV-In and component Y/Pb/Pr. A Touch USB Type-B port provides touch control from a computer.
Can the INF5522AG output to a second display?
Yes. The HDMI Out port connects to the HDMI input of another display and mirrors this display. The guide states that it works only with HDMI inputs 1 to 3, so sources on other inputs will not be passed through.
How should the INF5522AG be mounted?
The guide says two people must move and install the display because it is very heavy. It must be attached securely to a wall or stand using properly rated hardware and M6 screws, and it includes a section on mounting a camera. Procure.ae can advise on mounts and install it in the UAE.
Can I buy the INF5522AG in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
