InFocus INF5522AG 55-inch Interactive Flat Panel with Built-in Android PC

The InFocus INF5522AG is a 55-inch interactive flat panel with a built-in Android PC, four HDMI inputs, VGA, an HDMI output and RS-232 control. A bay on the back accepts an optional PC, and the hardware guide covers camera mounting. Procure.ae supplies it in the UAE.

The INF5522AG pairs a 55-inch touch display with an internal Android PC that has its own LAN port plus USB 2.0 and USB 3.0 ports. External sources connect through HDMI 1 to 3, HDMI 4 (which supports HDMI 2.0, HDCP 2.2 and MHL), VGA with a 3.5 mm PC audio input, composite AV-In and component Y/Pb/Pr. A Touch USB Type-B port links the panel to a computer for touch control.

The HDMI Out port mirrors HDMI inputs 1 to 3 to a second display, and audio leaves through SPDIF, a 3.5 mm headset jack or composite AV-Out. RS-232 in and out ports support control systems, and the panel is operated with a remote control or front keypad. Compared with the INF5512AG guide, the INF5522AG guide adds instructions for mounting a camera on the display.

Screen Size

55 inch

Type

Interactive Flat Panel with Built-in Android PC

Key features

55-inch display

A 55-inch diagonal panel mounted with M6 screws on suitably rated hardware.

Built-in Android PC

An internal Android PC has its own RJ45 LAN, USB 2.0 and two USB 3.0 ports.

Four HDMI inputs

HDMI 1 to 3 plus HDMI 4, which supports HDMI 2.0, HDCP 2.2 and MHL.

HDMI output

HDMI Out mirrors the display to a second screen from HDMI inputs 1 to 3.

Computer inputs

VGA with a 3.5 mm PC audio input, plus composite and component (Y/Pb/Pr) video.

Optional PC bay

A bay on the back of the panel holds an optional PC, with a dedicated OPS PC USB port.

Camera mounting

The hardware guide includes a procedure for mounting a camera on the display.

RS-232 control

RS-232 In and RS-232 Out ports support remote control applications.

Specifications

General
Controls	Remote control, front keypad, RS-232 In/Out
Key Features	55-inch panel, built-in Android PC, four HDMI inputs, HDMI Out, VGA, OPS PC bay, SPDIF out, RS-232 In/Out, camera mounting
Model	INF5522AG
Type	Interactive Flat Panel with Built-in Android PC

Display
Screen Size	55 inch

Performance
Operating System	Android (built-in PC)

Audio
Audio In	RCA L/R × 1, 3.5 mm PC audio × 1
Audio Out	SPDIF × 1, 3.5 mm headset × 1, composite AV-Out × 1

Connectivity
Ethernet	RJ45 LAN × 1 (for the Android PC)
HDMI Inputs	HDMI × 4 (HDMI 4 supports HDMI 2.0 / HDCP 2.2 and MHL)
HDMI Outputs	HDMI Out × 1 (mirrors HDMI 1 to 3)
Inputs	HDMI × 4, VGA × 1, composite AV-In × 1, component Y/Pb/Pr × 1, RCA L/R audio × 1, PC audio 3.5 mm × 1
OPS Slot	Optional PC bay on back of panel (OPS PC USB port)
Serial Port	RS-232 In × 1, RS-232 Out × 1
USB Ports	USB 2.0 × 1, USB 3.0 × 2 (to Android PC), Touch USB Type-B × 1, OPS PC USB × 1
VGA Input	VGA × 1

Physical
Mounting	Wall or stand mounting with M6 screws
