IIYAMADigital SignageSKU S2425AS-B1P
iiyama ProLite 23.8-inch Full HD Android Signage Display – S2425AS-B1P
The iiyama ProLite S2425AS-B1P is a 23.8-inch Full HD Android signage display for supermarkets, shops and information points. It has a 500 nits IPS panel, Power over Ethernet and iiSignage² software on Android 14 with Wi-Fi 6. Procure.ae is an authorised reseller of iiyama and supplies the S2425AS-B1P across the UAE.
The S2425AS-B1P uses a 1920 x 1080 IPS panel with 500 cd/m² brightness, 1,000:1 static contrast and a 14 ms response time (GTG). The specifications list flicker-free operation, and the 178° viewing angles keep content readable from the side. Power over Ethernet under IEEE 802.3at carries power and data on one RJ45 cable, while Android 14 runs iiSignage² CMS on the display. Two 5 W speakers, a microphone input and a USB-C video output are included.
The display is 28 mm deep and weighs 4.24 kg, which suits aisles, promotional zones and wall-mounted installations. Its 100 x 100 mm VESA pattern and landscape, portrait or face-up orientation give installers flexibility. It runs 24/7 with a 0 to 40 °C operating range. Compared with the 21.5-inch S2225AS-B1P, this model is larger and has a lower contrast ratio of 1,000:1 against 1,500:1.
Screen Size
23.8 inch
Resolution
1920 x 1080 (Full HD)
Brightness
500 nits
Type
Digital Signage Display
- Android 14 signage platform
- Power over Ethernet
- Full HD IPS panel
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Android 14 signage platform
iiSignage² CMS runs locally on the display.
02
Power over Ethernet
One RJ45 cable for data and power (IEEE 802.3at).
03
Full HD IPS panel
1920 x 1080 at 500 cd/m² with 178° viewing angles.
04
Flicker-free operation
Listed as flicker-free in the specifications.
05
Slim profile
28 mm depth and 4.24 kg for aisles and wall mounts.
06
Orientation options
Landscape, portrait or face-up with a 100 x 100 mm VESA pattern.
07
Wi-Fi 6 connectivity
Built-in 802.11ax wireless plus a 10/100/1000 Mbps Ethernet port.
08
Platform compatibility
iiyama states compatibility with this platform for at least five years.
Specifications
30 specificationsGeneral
Key FeaturesAndroid 14 OS, iiSignage² CMS, PoE single-cable installation, Wi-Fi 6, landscape, portrait and face-up orientation, flicker-free operation, 24/7 operation
ModelS2425AS-B1P
TypeDigital Signage Display
Display
Aspect Ratio16:9
Brightness500 nits
Color Depth16.7 million colours
Contrast Ratio1,000:1
OrientationLandscape, portrait, face-up
Panel TechnologyIPS
Refresh Rate60 Hz
Resolution1920 x 1080 (Full HD)
Response Time14 ms
Screen Size23.8 inch
Viewing Angle178° horizontal / 178° vertical
Performance
Operating SystemAndroid 14
Storage Conditions-20 to 60 °C
Audio
Speaker Output2 × 5 W
Connectivity
Input VoltageDC 12 V (external power supply)
PortsHDMI × 1, RJ45 (LAN) × 1 with PoE (IEEE 802.3at), microphone × 1
USB PortsUSB 2.0 × 1, USB 3.2 Gen 1 × 1
USB-C PortsUSB-C × 1 (5 Gbps, video output)
Wi-FiWi-Fi 6 (802.11ax/ac/a/b/g/n)
Power
Power Consumption17.5 W (typical)
Physical
Dimensions549.5 x 336.0 x 28.0 mm
Duty Cycle24/7
FinishBlack, matte bezel
Operating Temperature0 to 40 °C
VESA Mount100 x 100 mm
Weight4.24 kg
Compliance
CertificationsCE, EAC, RoHS, ErP, WEEE, REACH, UKCA
Downloads
Manufacturer documents for the iiyama ProLite 23.8-inch Full HD Android Signage Display – S2425AS-B1P — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What panel size and resolution does the S2425AS-B1P have?
It is a 23.8-inch display with a 1920 x 1080 (Full HD) IPS panel. The panel is 16:9, rated at 500 cd/m² brightness, with 1,000:1 static contrast and a 14 ms response time (GTG).
Can I power it over Ethernet?
Yes. The RJ45 port supports Power over Ethernet under IEEE 802.3at, so one cable carries both power and data. The unit also has an external 12 V DC power supply, with 17.5 W typical power use.
Can it be wall mounted?
Yes. It has a 100 x 100 mm VESA pattern and runs in landscape, portrait or face-up orientation. The manufacturer lists installation in aisles, promotional zones and wall-mounted positions, and the 28 mm depth suits a slim profile.
Does it need a separate media player?
No. The display runs Android 14 with iiSignage² CMS, so content can be managed and played back on the display itself. Wi-Fi 6 and an RJ45 Ethernet port provide the network connection.
Does it support touch?
No. The listed specifications include no touch input. The manufacturer describes the display as designed for content display where interaction is not required, so it suits information points. Installers can fit it with the standard 100 x 100 mm VESA pattern.
