Huawei Android OPS Slot-in PC – OPS A01 D

The Huawei OPS A01 D is an Android OPS-C slot-in PC built on the Rockchip RK3588 processor, with 8 GB of LPDDR5 memory and 128 GB of eMMC storage. It adds Wi-Fi 6, Bluetooth 5.2 and 4K 60 Hz HDMI input and output to compatible interactive flat panels. Procure.ae supplies it in the UAE.

The OPS A01 D uses an eight-core Rockchip RK3588 (four Cortex-A76 and four Cortex-A55 cores, up to 2.4 GHz) with G610 MC4 graphics and runs Android 15 and above. Memory is 8 GB of on-board dual-channel LPDDR5, and storage is 128 GB of eMMC. The front panel has three USB 3.2 Gen 1 ports, one USB 2.0 port, one USB Type-C port, a 4K 60 Hz HDMI input, a 4K 60 Hz HDMI output and two RJ45 LAN ports.

It is a standard OPS-C module. Its rear 80-pin connector carries a 4K 60 Hz HDMI output to the host panel, so it suits OPS-compatible interactive flat panels, conference whiteboards and digital signage displays. It supports Wi-Fi 6 and Bluetooth 5.2 through an M.2 E-Key 2230 slot and has two antennas. Cooling is passive, with noise below 35 dB at 1 m, and the rated power is 65 W from a 19 V DC input.
