DahuaInteractive Flat PanelsSKU LPH65-MC480-U-S2
Dahua MC480 Series 65-inch Interactive Flat Panel – LPH65-MC480-U-S2
The Dahua LPH65-MC480-U-S2 is a 65-inch 4K UHD interactive flat panel for classrooms, meeting rooms and boardrooms. It runs Android 15 with 16 GB RAM, offers 64-point infrared touch and has a 3840 x 2160 display at 500 cd/m². Procure.ae supplies it across the UAE.
The panel has a 65-inch 3840 x 2160 display with 500 cd/m² typical brightness, 1.07 billion colours at 10-bit depth and 90% NTSC colour gamut. Its 178° horizontal and vertical viewing angles keep content readable from the side of the room. Touch is infrared with 64 points, a 1.5 mm valid touch zone and palm rejection, and the 3.2 mm anti-glare tempered glass protects the surface. Pen writing supports finger input and a dual-colour pen, and the built-in 16-array microphone and four-speaker system suit lessons and presentations.
The LPH65-MC480-U-S2 runs Android 15 natively, and the manufacturer lists Windows 7, 8, 10 and 11 support through an external module. It has Wi-Fi 6, Bluetooth 5.4, three HDMI inputs, a DisplayPort input, and a USB-C port with 100 W fast charging and data transmission for bring-your-own-device use. It is designed for wall mounting or a mobile bracket, using a 600 x 400 mm hole pattern.
Screen Size
65 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Touch Technology
Infrared
- 65-inch 4K display
- Android 15 platform
- 64-point infrared touch
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
65-inch 4K display
3840 x 2160 resolution at 500 cd/m² typical brightness, with 1.07 billion colours at 10-bit depth.
02
Android 15 platform
Quad-core A76 and A55 processor with 16 GB RAM and 128 GB ROM.
03
64-point infrared touch
Pen and finger input with 1.5 mm valid touch, palm rejection and 3.2 mm anti-glare glass.
04
Built-in camera
3 × 50 MP Android camera with auto-framing, face detection and up to 9x digital zoom.
05
16-array microphone
Echo cancellation and noise filtering with a 0 to 12 m pickup distance.
06
HDMI and DisplayPort inputs
Three HDMI IN ports and one DP IN port, each supporting 4K at 60 Hz.
07
USB-C for BYOD
100 W fast charging, data transmission and local area network connection through one USB-C port.
08
Wall or mobile mounting
600 x 400 mm hole pattern for a wall mount or mobile bracket.
Specifications
39 specificationsGeneral
Key FeaturesAndroid 15, 4K UHD, 64-point touch, auto-framing, voice-tracking, 16-array microphone, Wi-Fi 6, Bluetooth 5.4
ModelLPH65-MC480-U-S2
TypeInteractive Flat Panel
Display
Aspect Ratio16:9
BacklightDLED
Bezel SizeTop 35.9 mm, sides 17.5 mm, bottom 40.7 mm
Brightness500 nits
Camera3 × 50 MP (Android), 8 MP video
Color Gamut90% NTSC
Contrast Ratio1,500:1 (typical)
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size65 inch
Touch Points64-point multi-touch
Touch TechnologyInfrared
Viewing Angle178° (H) / 178° (V)
Performance
GraphicsMali-G610 MC4
Operating SystemAndroid 15
ProcessorQuad-core A76 + Quad-core A55
RAM16 GB
Storage128 GB
Audio
Microphone16-array microphone
Pickup Range0 to 12 m
Speaker Configuration4 speakers, 2.2 channel
Speaker Output2 × 10 W + 2 × 20 W
Connectivity
BluetoothBluetooth 5.4
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 4, HDMI Out × 1, DP In × 1, USB 3.2 Type-A × 4, USB-C × 3
Wi-FiWi-Fi 6
Power
Power Consumption112 W (basic), 332 W (max)
Standby Power≤0.5 W
Physical
ColorBlack sides, Lunar Rock Gray top and bottom
Dimensions1446.6 x 962.9 x 116.2 mm
MaterialMetal casing
Operating Humidity10% to 90% RH
Operating Temperature0 to 40 °C
VESA Mount600 x 400 mm
Weight36 kg
Downloads
Manufacturer documents for the Dahua MC480 Series 65-inch Interactive Flat Panel – LPH65-MC480-U-S2 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Does the Dahua LPH65-MC480-U-S2 run Android or Windows?
It runs Android 15 natively, with 16 GB RAM and 128 GB ROM. The manufacturer's specifications also list Windows 7, 8, 10 and 11 support through an external module, so teams can use either platform.
What room size is the LPH65-MC480-U-S2 suited to?
It suits classrooms and meeting rooms where the audience sits within the viewing range of a 65-inch screen. The 178° viewing angles keep content visible from the side, and the 16-array microphone picks up voices up to 12 m away.
How is the LPH65-MC480-U-S2 mounted?
It can be wall-mounted or fitted to a mobile bracket. The manufacturer lists a 600 x 400 mm hole pattern and a net weight of 36 kg, so use wall fixings rated for that load. Procure.ae can advise on installation.
Does it connect to laptops and other devices?
Yes. It has three HDMI IN ports and a DisplayPort IN, all supporting 4K at 60 Hz. The USB-C port delivers 100 W fast charging and data transmission for bring-your-own-device use, and the panel includes Wi-Fi 6 and Bluetooth 5.4.
Does it have a built-in camera and microphone?
Yes. It includes an Android camera with 3 × 50 MP photo and 8 MP video, plus auto-framing and voice-tracking. A 16-array microphone with echo cancellation and noise filtering picks up sound up to 12 m away.
Can I buy the LPH65-MC480-U-S2 in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
