ViewSonicDigital SignageSKU CDE7530-E1
Viewsonic CDE7530-E1 - 75" Signage Display – CDE7530-E1
The Viewsonic CDE7530-E1 - 75" Signage Display – CDE7530-E1 is a digital signage available in the UAE from Procure.ae.
The Viewsonic CDE7530-E1 is a dynamic 75-inch signage display designed to deliver crisp visuals and seamless connectivity for professional environments. Ideal for digital signage in corporate, hospitality, and educational settings, this large-format 4K UHD display ensures content is always vibrant and impactful. The CDE7530-E1 boasts user-friendly features, including wireless screen sharing and a robust suite of connectivity options, making it a top choice for modern meeting rooms and collaborative spaces.
It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.
Screen Size
75 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Weight
34.65 kg
- 4K Ultra HD Resolution
- 75-Inch Large Format
- Wireless Screen Sharing
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
4K Ultra HD Resolution
Delivers breathtaking picture clarity with four times the detail of Full HD.
02
75-Inch Large Format
Expansive screen size ensures maximum visibility in any setting.
03
Wireless Screen Sharing
Effortlessly share content from laptops, tablets, and smartphones.
04
Integrated Content Management
Schedule and manage multimedia displays with intuitive software.
05
Multiple Connectivity Options
Includes HDMI, USB, and LAN ports for versatile integration.
06
24/7 Reliability
Engineered for continuous operation in demanding commercial environments.
07
Ultra-Narrow Bezel Design
Modern aesthetics that maximize display area and minimize distractions.
08
Energy-Efficient Operation
Reduces power consumption without compromising performance.
Specifications
40 specificationsGeneral
Key FeaturesAll-in-one solution includes CDE7530 display, Wi-Fi adapter and wall mount, Powerful ViewSonic Embedded Signage Platform (VESP), Integrated RJ45 and USB Wi-Fi, ViewBoard Cast content sharing software, myViewBoard Display app for remote screen sharing
What's in the BoxCDE7530 Wireless Presentation Display, Wi-Fi adapter and wall mount, Remote control with batteries, Quick Start Guide, Power cable, HDMI Cable, USB-C cable, Wall Mount, Screws and RS232 cable
Display
Aspect Ratio16:9
BacklightDirect LED
Bezel Size14.7 mm
Brightness500 nits
Color Depth10-bit (1.07 billion colours)
Contrast Ratio1,200:1 (typ.), 5,000:1 (DCR)
OrientationLandscape & Portrait
Panel TechnologyADS
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size75 inch
Viewing Angle178° (H) / 178° (V)
Performance
Operating SystemAndroid 11
ProcessorAmlogic T982
RAM4 GB
Storage32 GB
Audio
Audio OutSPDIF out × 1
Speaker Output2 × 10 W
Connectivity
BluetoothBuilt-in
EthernetRJ45 × 1
HDMI InputsHDMI In × 3
HDMI OutputsHDMI Out × 1
Input Voltage100–240 V AC
Serial PortRS-232 × 1
USB PortsUSB 3.0 × 1, USB 2.0 × 1
USB-C PortsUSB-C × 1
Wi-FiBuilt-in
Power
Power Consumption126 W (typical)
Standby Power≤ 0.5 W
Physical
Dimensions1685.6 x 963.7 x 81.6 mm
Duty Cycle24/7
Operating Humidity10% to 90% RH
Operating Temperature0°C to 40°C
Shipping Dimensions1863 x 1090 x 225 mm
Surface ProtectionAnti-glare, 3H hardness, 25% haze
VESA Mount800 x 600 mm, M8 x 25 mm
Weight34.65 kg
Compliance
Warranty3 years (parts, labor and backlight)
Downloads
Manufacturer documents for the Viewsonic CDE7530-E1 - 75" Signage Display – CDE7530-E1 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What is the ViewSonic digital signage used for?
The Viewsonic CDE7530-E1 is a dynamic 75-inch signage display designed to deliver crisp visuals and seamless connectivity for professional environments.
Does it include installation and warranty?
Procure.ae can arrange installation and provides manufacturer-backed warranty support. Contact us for the full warranty details applicable to this model.
What is this display used for?
It's a commercial digital signage display — ideal for menus, advertising, wayfinding, and information screens in retail, offices, and public spaces.
Can it run continuously for long hours?
Yes — commercial signage panels like this are built for extended daily operation; ask us for the exact operating-hours rating on this model.
How is the on-screen content managed?
