Viewsonic CDE7530-E1 - 75" Signage Display – CDE7530-E1

The Viewsonic CDE7530-E1 - 75" Signage Display – CDE7530-E1 is a digital signage available in the UAE from Procure.ae.

The Viewsonic CDE7530-E1 is a dynamic 75-inch signage display designed to deliver crisp visuals and seamless connectivity for professional environments. Ideal for digital signage in corporate, hospitality, and educational settings, this large-format 4K UHD display ensures content is always vibrant and impactful. The CDE7530-E1 boasts user-friendly features, including wireless screen sharing and a robust suite of connectivity options, making it a top choice for modern meeting rooms and collaborative spaces.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Screen Size

75 inch

Resolution

3840 x 2160 (4K UHD)

Brightness

500 nits

Weight

34.65 kg

Key features

4K Ultra HD Resolution

Delivers breathtaking picture clarity with four times the detail of Full HD.

75-Inch Large Format

Expansive screen size ensures maximum visibility in any setting.

Wireless Screen Sharing

Effortlessly share content from laptops, tablets, and smartphones.

Integrated Content Management

Schedule and manage multimedia displays with intuitive software.

Multiple Connectivity Options

Includes HDMI, USB, and LAN ports for versatile integration.

24/7 Reliability

Engineered for continuous operation in demanding commercial environments.

Ultra-Narrow Bezel Design

Modern aesthetics that maximize display area and minimize distractions.

Energy-Efficient Operation

Reduces power consumption without compromising performance.

Specifications

General
Key Features	All-in-one solution includes CDE7530 display, Wi-Fi adapter and wall mount, Powerful ViewSonic Embedded Signage Platform (VESP), Integrated RJ45 and USB Wi-Fi, ViewBoard Cast content sharing software, myViewBoard Display app for remote screen sharing
What's in the Box	CDE7530 Wireless Presentation Display, Wi-Fi adapter and wall mount, Remote control with batteries, Quick Start Guide, Power cable, HDMI Cable, USB-C cable, Wall Mount, Screws and RS232 cable

Display
Aspect Ratio	16:9
Backlight	Direct LED
Bezel Size	14.7 mm
Brightness	500 nits
Color Depth	10-bit (1.07 billion colours)
Contrast Ratio	1,200:1 (typ.), 5,000:1 (DCR)
Orientation	Landscape & Portrait
Panel Technology	ADS
Resolution	3840 x 2160 (4K UHD)
Response Time	8 ms
Screen Size	75 inch
Viewing Angle	178° (H) / 178° (V)

Performance
Operating System	Android 11
Processor	Amlogic T982
RAM	4 GB
Storage	32 GB

Audio
Audio Out	SPDIF out × 1
Speaker Output	2 × 10 W

Connectivity
Bluetooth	Built-in
Ethernet	RJ45 × 1
HDMI Inputs	HDMI In × 3
HDMI Outputs	HDMI Out × 1
Input Voltage	100–240 V AC
Serial Port	RS-232 × 1
USB Ports	USB 3.0 × 1, USB 2.0 × 1
USB-C Ports	USB-C × 1
Wi-Fi	Built-in

Power
Power Consumption	126 W (typical)
Standby Power	≤ 0.5 W

Physical
Dimensions	1685.6 x 963.7 x 81.6 mm
Duty Cycle	24/7
Operating Humidity	10% to 90% RH
Operating Temperature	0°C to 40°C
Shipping Dimensions	1863 x 1090 x 225 mm
Surface Protection	Anti-glare, 3H hardness, 25% haze
VESA Mount	800 x 600 mm, M8 x 25 mm
Weight	34.65 kg

Compliance
Warranty	3 years (parts, labor and backlight)
