BiampMeeting Room SolutionsSKU EasyConnect USB2-10-AB
Biamp EasyConnect 3 m USB 2.0 Type A to Type B Cable – USB2-10-AB
The Biamp EasyConnect USB2-10-AB is a 3 m (10-foot) USB 2.0 cable with Type A to Type B connectors and a data transfer speed of up to 480 Mbps. It is a passive cable for connecting USB 2.0 devices in video conferencing and AV setups. Procure.ae supplies it across the UAE.
The USB2-10-AB is a passive USB 2.0 cable with a Type A connector on one end and a Type B connector on the other. It carries data at up to 480 Mbps. The conductors are tinned copper in 24+28 AWG wire, the jacket is PVC, and a single braided shield surrounds the conductors. The contacts are gold plated, and the cable carries a UL-CMX safety rating along with RoHS, CE and FCC compliance.
Choose this model when a Type B device needs a 3 m run at USB 2.0 speed. Where a faster link is needed, the EasyConnect USB3-10-AB offers the same length and Type A to Type B connectors with 5 Gbps USB 3.2 Gen 1 data. The 2 m version is the EasyConnect USB2-6-AB. This part is listed under manufacturer model code 910-10216 and carries a 3-year warranty.
Type
USB 2.0 Cable
- USB 2.0 data rate
- Type A to Type B
- 3 m (10-foot) length
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
USB 2.0 data rate
Transfers data at up to 480 Mbps between connected devices.
02
Type A to Type B
Type A connector at one end and Type B connector at the other.
03
3 m (10-foot) length
Passive cable with no active signal amplification.
04
Shielded construction
A single braided shield with a PVC jacket and tinned copper conductors.
05
Gold-plated contacts
Contacts plated with gold, rated UL-CMX for safety.
06
Compliance and warranty
Lists RoHS, CE and FCC compliance and a 3-year warranty.
Specifications
13 specificationsGeneral
Key FeaturesUSB 2.0 at 480 Mbps, Type A to Type B, Passive signal, Single braided shield, Gold-plated contacts, PVC jacket, Tinned copper conductors, RoHS/CE/FCC compliant
ModelEasyConnect USB2-10-AB
TypeUSB 2.0 Cable
Connectivity
Cable StandardUSB 2.0
ConductorTinned copper, 24+28 AWG
Connector TypeUSB Type A to USB Type B
Data Rate480 Mbps
Jacket MaterialPVC
ShieldingSingle shielded (braid)
Physical
Length3 m (10 ft)
Compliance
CertificationsRoHS, CE, FCC
Safety RatingUL-CMX
Warranty3 years
Downloads
Manufacturer documents for the Biamp EasyConnect 3 m USB 2.0 Type A to Type B Cable – USB2-10-AB — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Is the EasyConnect USB2-10-AB a USB 2.0 cable?
Yes. The manufacturer lists it as a USB 2.0 cable with Type A to Type B connectors and a data transfer speed of up to 480 Mbps. It is not a USB 3.0 or USB-C cable.
How long is the EasyConnect USB2-10-AB?
It is 3 m (10 feet) long. The manufacturer lists it as a passive cable, which means it has no active signal amplification. Check your device's maximum cable length before ordering.
Does the USB2-10-AB use USB-C connectors?
No. It has a USB Type A connector on one end and a USB Type B connector on the other. Type B ports are commonly found on printers and some USB hubs, so confirm your device's port type before ordering.
Can I buy the EasyConnect USB2-10-AB in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
