BenQ InstaShow Wireless Presentation System – WDC10C
The BenQ InstaShow WDC10C is a plug-and-play USB-C wireless presentation system for huddle rooms with multiple presenters. It outputs up to 1080p at 60 Hz over HDMI 1.4 with HDCP, supports 16 connections and runs on 5 GHz Wi-Fi 5 with WPA2 encryption. Procure.ae supplies the BenQ InstaShow WDC10C across the UAE and wider MEA.
The WDC10C has a USB-C port and outputs up to 1080p at 60 Hz over HDMI 1.4 with HDCP. The manufacturer lists up to 16 connections and a range of up to 8 meters. Its Wi-Fi 5 link runs on 5 GHz only, at up to AC1200 data rates (867 Mbps on 5 GHz). WPA2 with AES128 encryption secures the session. The host measures 110 x 110 x 27 mm without antenna and weighs 150 g, and the kit includes two 2 dBi MIMO antennas, a cradle, an HDMI cable and a USB power cable.
The WDC10C suits huddle rooms and small team meetings where presenters connect over USB-C. Its resolution, connection count and range match the WDC10, and the difference is the USB-C port with a single USB power cable and no USB extension cable. Compared with the WDC15, the WDC10C outputs 1080p instead of 4K and uses WPA2 rather than WPA3.
Resolution
1920 x 1080 (Full HD)
Type
Wireless Presentation System
Weight
150 g
- Plug and Play
- USB-C Port
- 1080p at 60 Hz
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Plug and Play
Designed as a plug-and-play device with a USB-C port.
02
USB-C Port
Adds a USB-C port alongside the HDMI and USB power interface.
03
1080p at 60 Hz
Outputs up to 1080p at 60 Hz over HDMI 1.4 with HDCP.
04
16 Connections
Allows up to 16 connections to the receiver.
05
8-Meter Range
Works at a distance of up to 8 meters.
06
5 GHz Wi-Fi 5
Runs on 5 GHz only, with up to 867 Mbps data rates.
07
WPA2 Security
Encrypts the connection with WPA2 and AES128.
08
Compact Host
Measures 110 x 110 x 27 mm and weighs 150 g.
Specifications
18 specificationsGeneral
ApplicationHuddle rooms, multi-presenter meetings
Key FeaturesPlug and play, USB-C port, 1080p 60 Hz output, 16 connections, 8 m range, Wi-Fi 5 on 5 GHz, WPA2 with AES128
ModelWDC10C
TypeWireless Presentation System
What's in the BoxHost receiver, cradle, HDMI cable, USB power cable (150 cm), 2 antennas
Display
Refresh Rate60 Hz
Resolution1920 x 1080 (Full HD)
Connectivity
Antenna2 × 2 dBi MIMO
Data RateAC1200 (5 GHz 867 Mbps)
HDMI OutputsHDMI 1.4 (HDCP)
PortsHDMI out × 1, USB-C × 1, LAN (RJ45) × 1
USB-C PortsUSB-C × 1
Wi-FiWi-Fi 5
Power
Power Consumption5 W (normal)
Power SourceDC 5 V, 1.5 A
Physical
Dimensions110 x 110 x 27 mm
Weight150 g
Compliance
Security FeaturesWPA2, AES128 encryption
Downloads
Manufacturer documents for the BenQ InstaShow Wireless Presentation System – WDC10C — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Does the WDC10C need software?
No. The manufacturer describes the WDC10C as a plug-and-play device with a USB-C port. It shares the WDC10's HDMI output and its 16-connection limit, and the kit includes a cradle, an HDMI cable and two antennas.
Does the WDC10C have a USB-C port?
Yes. The WDC10C includes a USB-C port. Its button interface is listed as HDMI with USB power, or USB Type-C, and it includes a 150 cm USB power cable. The WDC10 uses the same HDMI and USB power connection without the USB-C port.
What is the maximum output resolution of the WDC10C?
Up to 1080p at 60 Hz over HDMI 1.4 with HDCP. For 4K output, the BenQ WDC15 is listed at 4K 30 Hz and the WDC25 at 4K 60 Hz over HDMI.
Is the WDC10C suited to huddle rooms?
Yes. The manufacturer positions the WDC10C for huddle rooms, with a range of up to 8 meters and up to 16 connections, the same figures listed for the WDC10. Check the room layout against that range before installation.
