Angekis Saber Plus 1080p 20x Zoom PTZ Camera – Saber Plus (IP-20FHD60)
The Angekis Saber Plus (IP-20FHD60) is a full HD PTZ conference camera for video conferencing rooms. It outputs 1920 x 1080 video at up to 60 fps, offers 20x optical zoom and supports PoE on a 1000 Mbps network. Procure.ae supplies the Angekis Saber Plus in the UAE, with quotes, delivery and installation.
The Saber Plus uses a 1/2.8-inch, 5 megapixel CMOS sensor with 20x optical zoom and 2x digital zoom. Its focal length runs from 5.2 mm at the wide end to 98 mm at telephoto, with a 60° diagonal field of view. Pan covers -170° to +170° and tilt covers -35° to +90°, at up to 120° per second pan and 80° per second tilt. The camera is rated at 0.01 lux minimum illumination and a signal-to-noise ratio above 50 dB, with 2D and 3D noise reduction and WDR support.
The camera outputs video over HDMI, SDI, USB 3.0 and USB 2.0, and streams over IP with TCP/IP, HTTP, RTSP, ONVIF and DHCP. It supports H.264 and H.265 encoding, with H.264 as the default. Control is available from the remote controller with 10 presets, or over RS232 and RS485 with up to 128 RS232 presets, and up to seven cameras can be daisy-chained on RS232. Procure.ae can advise on cabling and integration for your room.
Resolution
1920 x 1080 (Full HD)
Speed
Pan up to 120°/s, tilt up to 80°/s
Type
PTZ Camera
- 1080p60 video output
- 20x optical zoom
- Wide pan and tilt range
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
1080p60 video output
1920 x 1080 at up to 60 fps over HDMI, SDI and USB 3.0.
02
20x optical zoom
20x optical and 2x digital zoom with a 60° diagonal field of view.
03
Wide pan and tilt range
Pan -170° to +170° and tilt -35° to +90°, at up to 120°/s pan and 80°/s tilt.
04
Low-light operation
0.01 lux minimum illumination, with 2D and 3D noise reduction and WDR.
05
PoE and 1000M network
PoE support with TCP/IP, HTTP, RTSP, ONVIF and DHCP protocols.
06
RS232 and RS485 control
128 RS232 presets and 10 presets on the remote controller.
07
Daisy-chain control
Up to seven cameras can be daisy-chained on a single RS232 chain.
08
Image settings
Auto and manual white balance, focus, shutter and backlight compensation, with mirror and flip modes.
Specifications
17 specificationsGeneral
ApplicationVideo conferencing
ControlsRemote controller, RS232, RS485
Key Features20x optical zoom, 1080p60 output, PoE, H.264/H.265 encoding, RS232 daisy chain up to 7 cameras, 128 RS232 presets, WDR, 0.01 lux minimum illumination
ModelSaber Plus
TypePTZ Camera
Display
Camera1/2.8-inch, 5 MP CMOS sensor
Resolution1920 x 1080 (Full HD)
Zoom20x optical, 2x digital
Performance
SpeedPan up to 120°/s, tilt up to 80°/s
Audio
Signal-to-Noise Ratio>50 dB
Connectivity
ConnectivityRS232, RS485, RJ45 (control)
Ethernet1000 Mbps
Input VoltageDC 12 V, 2 A
PoESupported
PortsHDMI, SDI, USB 3.0, USB 2.0, RJ45
ProtocolsTCP/IP, HTTP, RTSP, ONVIF, DHCP
Physical
RotationPan -170° to +170°, tilt -35° to +90°
Downloads
Manufacturer documents for the Angekis Saber Plus 1080p 20x Zoom PTZ Camera – Saber Plus (IP-20FHD60) — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Does the Saber Plus output 1080p video over HDMI, SDI and USB?
Yes. The manufacturer lists 1920 x 1080 progressive output at 60, 50, 30 and 25 fps over HDMI, SDI and USB 3.0, with 24, 59.94 and 29.97 fps also available over HDMI and SDI. Lower 1280 x 720 modes are listed as well.
Does the Saber Plus work on an IP network with PoE?
Yes. The Saber Plus supports PoE and a 1000 Mbps network connection. It uses TCP/IP, HTTP, RTSP, ONVIF and DHCP, and encodes video as H.264 by default, with H.265 also supported.
How is the Saber Plus controlled?
The camera can be controlled from its remote controller, which stores 10 presets, or over RS232 and RS485, which store up to 128 presets. Up to seven cameras can be daisy-chained on RS232. Procure.ae can advise on the controller and cabling for your control system.
What zoom and field of view does the Saber Plus offer?
The Saber Plus offers 20x optical zoom and 2x digital zoom. Its focal length runs from 5.2 mm at the wide end to 98 mm at telephoto, with a 60° diagonal field of view. The minimum focus distance is 0.3 metres at wide and 1 metre at telephoto.
Can the Saber Plus be wall-mounted?
The manufacturer's specifications do not list mounting options for the Saber Plus. Angekis lists a wall bracket for PTZ cameras in black and white, but its fit with this model is not stated, so Procure.ae can confirm compatibility before you order.
Can I buy the Saber Plus (IP-20FHD60) in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
