Angekis Saber Plus 1080p 20x Zoom PTZ Camera – Saber Plus (IP-20FHD60)

The Angekis Saber Plus (IP-20FHD60) is a full HD PTZ conference camera for video conferencing rooms. It outputs 1920 x 1080 video at up to 60 fps, offers 20x optical zoom and supports PoE on a 1000 Mbps network. Procure.ae supplies the Angekis Saber Plus in the UAE, with quotes, delivery and installation.

The Saber Plus uses a 1/2.8-inch, 5 megapixel CMOS sensor with 20x optical zoom and 2x digital zoom. Its focal length runs from 5.2 mm at the wide end to 98 mm at telephoto, with a 60° diagonal field of view. Pan covers -170° to +170° and tilt covers -35° to +90°, at up to 120° per second pan and 80° per second tilt. The camera is rated at 0.01 lux minimum illumination and a signal-to-noise ratio above 50 dB, with 2D and 3D noise reduction and WDR support.

The camera outputs video over HDMI, SDI, USB 3.0 and USB 2.0, and streams over IP with TCP/IP, HTTP, RTSP, ONVIF and DHCP. It supports H.264 and H.265 encoding, with H.264 as the default. Control is available from the remote controller with 10 presets, or over RS232 and RS485 with up to 128 RS232 presets, and up to seven cameras can be daisy-chained on RS232. Procure.ae can advise on cabling and integration for your room.

Resolution

1920 x 1080 (Full HD)

Speed

Pan up to 120°/s, tilt up to 80°/s

Type

PTZ Camera

Key features

1080p60 video output

1920 x 1080 at up to 60 fps over HDMI, SDI and USB 3.0.

20x optical zoom

20x optical and 2x digital zoom with a 60° diagonal field of view.

Wide pan and tilt range

Pan -170° to +170° and tilt -35° to +90°, at up to 120°/s pan and 80°/s tilt.

Low-light operation

0.01 lux minimum illumination, with 2D and 3D noise reduction and WDR.

PoE and 1000M network

PoE support with TCP/IP, HTTP, RTSP, ONVIF and DHCP protocols.

RS232 and RS485 control

128 RS232 presets and 10 presets on the remote controller.

Daisy-chain control

Up to seven cameras can be daisy-chained on a single RS232 chain.

Image settings

Auto and manual white balance, focus, shutter and backlight compensation, with mirror and flip modes.

Specifications

General
Application	Video conferencing
Controls	Remote controller, RS232, RS485
Key Features	20x optical zoom, 1080p60 output, PoE, H.264/H.265 encoding, RS232 daisy chain up to 7 cameras, 128 RS232 presets, WDR, 0.01 lux minimum illumination
Model	Saber Plus
Type	PTZ Camera

Display
Camera	1/2.8-inch, 5 MP CMOS sensor
Resolution	1920 x 1080 (Full HD)
Zoom	20x optical, 2x digital

Performance
Speed	Pan up to 120°/s, tilt up to 80°/s

Audio
Signal-to-Noise Ratio	>50 dB

Connectivity
Connectivity	RS232, RS485, RJ45 (control)
Ethernet	1000 Mbps
Input Voltage	DC 12 V, 2 A
PoE	Supported
Ports	HDMI, SDI, USB 3.0, USB 2.0, RJ45
Protocols	TCP/IP, HTTP, RTSP, ONVIF, DHCP

Physical
Rotation	Pan -170° to +170°, tilt -35° to +90°

QR code to Angekis Saber Plus 1080p 20x Zoom PTZ Camera – Saber Plus (IP-20FHD60) on procure.ae

Get our best price for this product

Scan to open it on procure.ae, or contact the Procure sales team:
☎ +971 4 546 5041 · WhatsApp · ✉ info@procure.ae · 🔗 View product page

This sheet is compiled from the product data held on procure.ae. For fully accurate and up-to-date figures, always refer to the manufacturer’s own specification sheet or datasheet for this model.

Specifications are provided by the manufacturer and may change without notice.

Pricing is quote-based. Contact Procure for current pricing and availability.

Delivery across the UAE and beyond, installation on request and manufacturer-backed warranty.
