VSYS VPM-20-H Universal Projector Interface Bracket for 1.5" NPT Pipe, 35 kg

The VSYS VPM-20-H is a universal projector interface bracket that couples a projector of up to 35 kg to a standard 1.5" NPT ceiling pipe, available in the UAE from Procure.ae.

This is an interface component rather than a complete ceiling kit. It supplies the projector-side head and the pipe coupling only, so the drop pipe, ceiling plate and any structural fixings are specified separately to suit the slab, joist or suspended grid above. That separation is what integrators usually want on fit-out work, because the pipe length can be cut to the exact room height while the head itself stays a single, repeatable line item across every room in the building.

Adjustable arms slide in and out to meet the projector chassis hole pattern, so alignment is not tied to a VESA standard. Once the chassis is captured, the head tilts 20 degrees either side of level, swivels 8 degrees either way and rotates a full 180 degrees in both directions, which lets an off-centre ceiling position still square the image to the screen. Drop is adjustable from 130 mm to 470 mm, and cables run through the arms rather than hanging beside them.

It is supplied to corporate, education, hospitality and government organisations across the UAE, with procurement-ready quotations and regional delivery.
