ViewSonic ViewBoard OPS Slot-in PC – VPCF5-S55-G1

The ViewSonic VPCF5-S55-G1 is a slot-in PC (OPS) for ViewBoard interactive displays. It uses an 11th Gen Intel Core i5 or later processor with 16 GB memory, a 512 GB PCIe SSD and Wi-Fi 6 with Bluetooth 5.2. Its graphics output reaches 7680 x 4320 at 60 Hz over DisplayPort. Procure.ae supplies the VPCF5-S55-G1 in the UAE.

The VPCF5-S55-G1 uses an 11th Gen Intel Core i5 (Tiger Lake) processor or later, with Intel Iris Xe Graphics at 96 execution units and 32 GB of total available graphics memory. It has 16 GB of DDR4 memory and a 512 GB PCIe SSD. Intel Wi-Fi 6 AX101 and Bluetooth 5.2 are built in, with an RJ45 LAN port at 10/100/1000 Mbps, USB 3.1 and USB 2.0 Type-A ports, a USB-C data port and a combined mic-in and line-out jack. It draws up to 90 W from a 12–19 V DC supply.

The VPCF5-S55-G1 is designed to sync with ViewBoard interactive displays and Presentation Displays. The manufacturer lists UEFI Shell as the operating system. The module measures 200 x 119 x 30 mm, weighs 0.7 kg net and operates from 0 to 40 °C. The manufacturer's specifications do not state a VESA pattern or mounting kit for the module, so confirm the fitting before ordering. Compared with the VPCF5-S33-G1, it doubles the memory to 16 GB and the storage to 512 GB.

Type

OPS Slot-in PC

Weight

0.7 kg

Key features

16 GB memory

16 GB of DDR4 memory on the module.

512 GB PCIe SSD

512 GB M.2 SSD on a PCIe interface.

11th Gen processing

Intel Core i5 (Tiger Lake) or later processor.

High-resolution output

Intel Iris Xe Graphics with 96 execution units, up to 7680 x 4320 at 60 Hz over DisplayPort.

Wireless connectivity

Intel Wi-Fi 6 AX101 with Bluetooth 5.2.

Wired connectivity

RJ45 LAN at 10/100/1000 Mbps, USB 3.1 and USB 2.0 Type-A ports, and a USB-C data port.

OPS standard connector

The OPS x1 connector provides USB 3.1 Type-A ports, a USB-C 3.1 data port and USB 2.0.

Low power draw

Up to 90 W maximum consumption from a 12–19 V DC supply.

Specifications

General
Key Features	11th Gen Intel Core i5, 16 GB DDR4, 512 GB PCIe SSD, Iris Xe Graphics, DisplayPort up to 8K, Wi-Fi 6, Bluetooth 5.2, RJ45 LAN
Model	VPCF5-S55-G1
Type	OPS Slot-in PC
What's in the Box	Quick Start Guide, 2 screws, 2 antennas

Performance
Graphics	Intel Iris Xe Graphics (96 EU), 32 GB total available graphics memory
Operating System	UEFI Shell
Processor	Intel 11th Gen Core i5 (Tiger Lake) or later
RAM	16 GB DDR4
Storage	512 GB PCIe M.2 SSD

Audio
DisplayPort	Up to 7680 x 4320 at 60 Hz

Connectivity
Bluetooth	Bluetooth 5.2
Ethernet	RJ45 LAN, 10/100/1000 Mbps
Input Voltage	DC 12–19 V, 8 A (max)
OPS Slot	OPS standard x1
Ports	USB 3.1 Type-A × 2, USB 2.0 Type-A × 1, USB-C 3.1 Gen 2 × 1 (data only), Mic-in/Line-out combo × 1
Wi-Fi	Intel Wi-Fi 6 AX101, 802.11ax

Power
Power Consumption	90 W (max)

Physical
Dimensions	200 x 119 x 30 mm
Operating Humidity	10% to 90% RH at 40 °C, non-condensing
Operating Temperature	0 to 40 °C
Weight	0.7 kg

Compliance
Certifications	CE EMC, LVD, CE RED, RoHS, REACH, WEEE, CB2018
