ViewSonicInteractive Flat PanelsSKU IFP7533
ViewSonic ViewBoard IFP33 Series 75-inch 4K Interactive Flat Panel – IFP7533
The ViewSonic IFP7533 is a 75-inch 4K UHD interactive flat panel for classrooms and collaborative teaching. It has an IPS panel, 40-point Ultra Fine Touch with dual-tip pen support and 400 nits brightness. Procure.ae supplies the ViewSonic IFP7533 across the UAE.
The IFP7533 has a 75-inch 4K UHD IPS panel at 3840 x 2160 resolution, with 400 nits brightness, a 5,000:1 maximum contrast ratio with DCR enabled, an 8 ms response time and 178-degree viewing angles. Ultra Fine Touch Technology supports 40 touch points with fingers or dual-tip pens, and the built-in front-facing speakers add audio for lessons. The quad-core ARM Cortex-A55 processor has 4 GB of DDR4 RAM and 32 GB of storage. A light sensor, plus optional OPS and WiFi modules, extends the system for classroom use.
The IFP7533 suits classrooms, lesson spaces and training rooms where teachers run lessons and manage devices. The panel is preinstalled with myViewBoard for lesson delivery, and Viewboard Cast supports wireless casting with touch feedback. Compared with the IFP7533-G, it has 4 GB of RAM and 32 GB of storage instead of 8 GB and 128 GB, with the same panel and ports. The 800 x 400 mm VESA pattern, two RJ45 ports and USB 3.0 Type A ports connect it to sources. Procure.ae is an authorised ViewSonic reseller.
Screen Size
75 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
400 nits
Touch Technology
Ultra Fine Touch
- 75-inch 4K IPS panel
- Ultra Fine Touch
- Front-facing speakers
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
75-inch 4K IPS panel
3840 x 2160 resolution, 400 nits brightness and 178-degree viewing angles.
02
Ultra Fine Touch
40-point touch that works with fingers or dual-tip pens.
03
Front-facing speakers
Built-in speakers for classroom audio, plus a USB-C port for multimedia.
04
myViewBoard preinstalled
MyViewBoard for lesson delivery and device management tools for administrators.
05
Viewboard Cast
Wireless casting with touch feedback.
06
Processor and memory
Quad-core ARM Cortex-A55 with 4 GB DDR4 RAM and 32 GB storage.
07
Expansion slots
OPS slot for optional Intel standard OPS and WiFi slot for optional modules.
08
Ports
RGB/VGA, RS232, two RJ45, four USB 3.0 Type A, one USB 2.0 Type A, two USB Type B and one USB-C.
Specifications
27 specificationsGeneral
Key FeaturesUltra Fine Touch with 40 points, dual-tip pen support, preinstalled myViewBoard, Viewboard Cast with touch feedback, front-facing speakers, light sensor, USB-C with PD 65 W, 4K IPS panel
ModelIFP7533
TypeInteractive Flat Panel
Display
Aspect Ratio16:9
BacklightDLED
Brightness400 nits
Contrast Ratio5,000:1 (max., with DCR)
Panel TechnologyIPS
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size75 inch
Touch Points40-point multi-touch
Touch TechnologyUltra Fine Touch
Viewing Angle178° horizontal, 178° vertical
Performance
ProcessorQuad-core ARM Cortex-A55
RAM4 GB
Storage32 GB
Connectivity
Input Voltage100–240 V AC
OPS SlotOPS slot × 1 (optional Intel standard OPS)
PortsRGB/VGA × 1, RS232 × 1, RJ45 × 2, USB 3.0 Type A × 4, USB 2.0 Type A × 1, USB Type B × 2, USB-C × 1, audio in × 1, audio out × 1
Wi-FiWiFi slot × 1 (optional VB-WIFI-002, VB-WIFI-004 or VSB-050)
Power
Power Consumption106 W (on), at most 0.5 W (off)
Physical
Dimensions1709 x 1020 x 88 mm
Operating Humidity20% to 80% RH (non-condensing)
Operating Temperature0 to 40 °C
VESA Mount800 x 400 mm
Weight47.3 kg
Downloads
Manufacturer documents for the ViewSonic ViewBoard IFP33 Series 75-inch 4K Interactive Flat Panel – IFP7533 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What are the screen size, resolution and panel type of the IFP7533?
It is a 75-inch 4K UHD display at 3840 x 2160 resolution in a 16:9 aspect ratio, with an IPS panel and DLED backlight. Brightness is 400 nits and the response time is 8 ms.
Does the IFP7533 support pen and finger touch?
Yes. It has Ultra Fine Touch Technology with 40 touch points. Users can write with fingers or dual-tip pens for a pen-on-paper experience, and myViewBoard provides the annotation software. Dual-tip pens suit writing on the 4K IPS panel during lessons.
Is the IFP7533 suitable for a classroom?
Yes. It is designed as a classroom display for teachers and students, with myViewBoard preinstalled for lesson delivery. The 40-point touch supports group work, and the front-facing speakers provide audio in the room.
How is the IFP7533 mounted, and what size is the VESA pattern?
It uses an 800 x 400 mm VESA pattern. The display measures 1709 x 1020 x 88 mm and weighs 47.3 kg net, so use a wall mount rated for that weight and follow the manufacturer's installation guidance.
Can the IFP7533 connect to a PC or slot-in device?
Yes. It has RGB/VGA input, a USB-C port with DP 1.2 and PD 65 W, and an OPS slot for an optional Intel standard OPS PC. Simple LAN sharing between the panel and a slot-in device runs at 10/100 Mbps.
