ViewSonic · IFP6550-5 · Interactive Flat Panel

ViewSonic ViewBoard 65-inch 4K Interactive Display – IFP6550-5

ViewSonic ViewBoard 65-inch 4K Interactive Display – IFP6550-5

The ViewSonic ViewBoard IFP6550-5 is a 65-inch 4K UHD interactive flat panel for classrooms and collaborative teaching spaces. It has a 3840 × 2160 IR touch panel with up to 40-point touch on Windows, a single USB-C connection with 65W power delivery, and myViewBoard annotation software. Procure.ae supplies the ViewBoard IFP6550-5 across the UAE.

The ViewBoard IFP6550-5 pairs a 65-inch IPS LCD panel at 3840 × 2160 UHD resolution with 10-bit colour and 350 nits typical brightness. Ultra Fine Touch infrared technology offers up to 40-point touch on Windows and 20 points on Android, on a 7H anti-glare surface. Compute comes from an ARM Cortex-A73 and Cortex-A53 processor with 4GB RAM and 32GB storage. A single USB-C port carries DisplayPort 1.2, USB 2.0, 100M Ethernet and 65W power delivery, so one cable can connect a laptop.

The IFP6550-5 suits classrooms and teaching spaces, as it is designed with modern educators in mind. It includes myViewBoard basic annotation software, and myViewBoard for Windows runs in the embedded slot-in PC. Wireless presentation works through vCast, the myViewBoard Display App or AirSync, and the panel supports a 600 mm × 400 mm VESA wall mount. A light sensor, a dual pen available in several colours and sizes, and a TÜV certified blue light filter add to everyday use.

Screen Size
65 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
350 nits
Touch Technology
Infrared
Type
Interactive Flat Panel
Weight
40.1 kg

Key features

01
65-inch 4K UHD panel
3840 × 2160 resolution with 10-bit colour and 350 nits typical brightness.
02
Ultra Fine Touch
up to 40-point touch on Windows and 20 points on Android for multi-user writing.
03
Single-cable USB-C
one port with DisplayPort 1.2, USB 2.0, 100M Ethernet and 65W power delivery.
04
Dual-pen writing
a dual pen available in several colours and sizes for smooth writing.
05
myViewBoard software
basic and Pro annotation software, with myViewBoard for Windows in the slot-in PC.
06
Wireless presentation
vCast, myViewBoard Display App and AirSync support wireless sharing.
07
Eye-care features
Flicker-Free technology and a TÜV certified blue light filter at all brightness levels.
08
Expansion and connectivity
two RJ45 ports, a WiFi module slot, an OPS slot and RS232 for integration.

Specifications

General
Key FeaturesInfrared touch, light sensor, OPS slot for slot-in PC, wireless presentation, annotation software, LAN sharing with slot-in PC, Wi-Fi module slot
ModelIFP6550-5
TypeInteractive Flat Panel
Display
Aspect Ratio16:9
BacklightDLED
Brightness350 nits
Color Depth10-bit (1.07 billion colors)
Contrast Ratio1,200:1
OrientationLandscape
Panel TechnologyIPS
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size65 inch
Touch Points40-point (Windows) / 20-point (Android) multi-touch
Touch Resolution32768 x 32768
Touch TechnologyInfrared
Viewing Angle178° (H) / 178° (V)
Performance
ProcessorARM Cortex-A73 × 4 + Cortex-A53 × 4
RAM4 GB
Storage32 GB
Audio
Audio OutEarphone × 1
Connectivity
EthernetRJ45 × 2
Input Voltage100–240 V AC
OPS Slot1 slot
Serial PortRS232 × 1
Touch USB PortsUSB-B × 2
USB PortsUSB 2.0 × 2, USB 3.0 × 4
USB-C PortsUSB-C × 1 (DP 1.2, USB 2.0, PD 65 W, 100M Ethernet)
Power
Power Consumption95 W (typical)
Standby Power<0.5 W
Physical
Dimensions1488.4 x 896.7 x 86.5 mm
Operating Humidity10% to 90% RH
Operating Temperature0 to 40 °C
Shipping Dimensions1628 x 1005 x 208 mm
Shipping Weight50.7 kg
Surface Protection7H, anti-glare coating
VESA Mount600 x 400 mm
Weight40.1 kg
