ViewSonic OPS Slot-in PC for ViewBoard – VPC25-S33-O1-1B

The ViewSonic VPC25-S33-O1-1B is a compact slot-in PC for ViewBoard interactive displays and wireless presentation displays. It has an Intel Core i5-10400T processor, 8 GB of DDR4 memory and a 256 GB NVMe SSD, with Bluetooth 5.2 and dual-band Wi-Fi. Procure.ae supplies it across the UAE.

The VPC25-S33-O1-1B is a compact slot-in PC for ViewBoard interactive displays and wireless presentation displays. It uses an Intel Core i5-10400T processor from the 10th Gen Core family, with a 2.0 GHz base clock, turbo up to 3.6 GHz and TPM 2.0 support. The module has 8 GB of DDR4 memory and a 256 GB NVMe PCIe Gen3 SSD, with an Intel UHD Graphics 630 GPU on the Intel H510 chipset.

Connectivity includes dual-band Wi-Fi, Bluetooth 5.2, a DisplayPort 1.2 output that supports 3840 x 2160 at 60 Hz, a Gigabit LAN port, USB 3.2 and USB 2.0 ports, and a USB-C data port. The module is powered from a DC input of +12 V to +19 V and is rated at 65 W typical. The manufacturer's specifications list the operating system as UEFI Shell, so the module does not ship with Windows. Procure.ae supplies it across the UAE.

Type

OPS Slot-in PC

Weight

1 kg

Key features

Intel Core i5-10400T

10th Gen processor with turbo up to 3.6 GHz.

8 GB DDR4 memory

Memory for display sync and classroom sessions.

256 GB NVMe SSD

M.2 2280 PCIe Gen3 solid-state storage.

4K HDMI via DisplayPort

DisplayPort 1.2 supports 3840 x 2160 at 60 Hz.

Bluetooth 5.2 and dual-band Wi-Fi

Wireless connectivity for presentation and sync.

Gigabit LAN

One GbE LAN port for wired networking.

USB ports

USB 3.2 × 1, USB 2.0 × 3 and a USB-C data port.

TPM 2.0 support

The manufacturer lists TPM 2.0 support with the processor.

Specifications

General
Key Features	Intel Core i5-10400T, 8 GB DDR4, 256 GB NVMe SSD, Bluetooth 5.2, dual-band Wi-Fi, 4K HDMI via DP 1.2, GbE LAN, TPM 2.0
Model	VPC25-S33-O1-1B
Type	OPS Slot-in PC
What's in the Box	Slot-in PC module

Performance
Graphics	Intel UHD Graphics 630 with Intel H510 chipset
Operating System	UEFI Shell
Processor	Intel Core i5-10400T, 2.0 GHz base, up to 3.6 GHz turbo (10th Gen, TPM 2.0)
RAM	8 GB DDR4
Storage	256 GB SSD (NVMe PCIe Gen3)

Connectivity
Bluetooth	Bluetooth 5.2
Input Voltage	DC input +12 V to +19 V, 3.42 A
Ports	USB 3.2 × 1, USB 2.0 × 3, USB-C × 1 (data only), DisplayPort 1.2 × 1, GbE LAN × 1, Line out × 1, Microphone × 1
Wi-Fi	Dual-band Wi-Fi

Power
Power Consumption	65 W (typical)

Physical
Dimensions	202 x 119 x 30 mm
Operating Humidity	20% to 80% RH (non-condensing)
Operating Temperature	-5 to 45 °C
Weight	1 kg
