ViewSonic CDE Series 86-inch 4K Digital Signage Display – CDE8614-2C
The ViewSonic CDE8614-2C is an 86-inch 4K UHD commercial display built for 24/7 operation in offices, retail spaces and transit hubs. It offers 500 nits of brightness, Android 14 on a quad-core processor, and landscape or portrait mounting. Procure.ae supplies the CDE8614-2C across the UAE, with quotes, delivery and installation.
The CDE8614-2C uses a 3840 x 2160 (4K UHD) TFT LCD panel with DLED backlight, 500 nits typical brightness and an 8 ms response time. Its 1,200:1 typical contrast ratio rises to 2,000:1 with dynamic contrast ratio (DCR) enabled, and viewing angles are 178 degrees horizontally and vertically. A quad-core ARM Cortex-A73 processor with 4 GB RAM and 32 GB storage runs Android 14 for fast warm boot and smooth multitasking. Continuous USB media playback with auto signal failover keeps content running if the primary source is lost.
The display suits corporate lobbies, retail floors, transit hubs and meeting spaces. ViewSonic Manager provides remote device management, and AirSync supports wireless presentation. It integrates with leading Pro AV control systems through its RS-232 port and RJ45 Ethernet port. The USB-C port carries DisplayPort 1.2 and 15 W power delivery, and a Wi-Fi slot is fitted. Unlike the larger CDE31 Series, this model has no OPS slot and 4 GB RAM instead of 8 GB.
Key features
Specifications
| Key Features | Android 14, AirSync wireless presentation, ViewSonic Manager remote management, USB media playback with auto signal failover, landscape and portrait, anti-glare 3H surface, 24/7 operation |
| Model | CDE8614-2C |
| Type | Digital Signage Display |
| Aspect Ratio | 16:9 |
| Backlight | DLED |
| Bezel Size | 15.9 mm |
| Brightness | 500 nits |
| Contrast Ratio | 1,200:1 (typical; 2,000:1 with DCR) |
| Display Type | Commercial LCD display |
| Orientation | Landscape and portrait |
| Panel Technology | LCD |
| Resolution | 3840 x 2160 (4K UHD) |
| Response Time | 8 ms |
| Screen Size | 86 inch |
| Viewing Angle | 178° horizontal / 178° vertical |
| Operating System | Android 14 |
| Processor | Quad-core ARM Cortex-A73 |
| RAM | 4 GB |
| Storage | 32 GB |
| Input Voltage | 100–240 V AC ±10% |
| Ports | RS-232 × 1, Wi-Fi slot × 1, RJ45 × 1, USB 2.0 × 2, USB-C × 1 (DisplayPort 1.2, 15 W PD) |
| Power Consumption | 120.95 W |
| Dimensions | 1930.8 x 1101.7 x 68 mm |
| Operating Humidity | 20% to 80% RH (non-condensing) |
| Operating Temperature | 0 to 40 °C |
| VESA Mount | 600 x 400 mm |
| Weight | 42 kg |
| Certifications | ENERGY STAR |
☎ +971 4 546 5041 · WhatsApp · ✉ info@procure.ae · 🔗 View product page
This sheet is compiled from the product data held on procure.ae. For fully accurate and up-to-date figures, always refer to the manufacturer’s own specification sheet or datasheet for this model.
Specifications are provided by the manufacturer and may change without notice.
Pricing is quote-based. Contact Procure for current pricing and availability.
Delivery across the UAE and beyond, installation on request and manufacturer-backed warranty.
