ViewSonic CDE Series 55-inch 4K Digital Signage Display – CDE5514-2C
The ViewSonic CDE5514-2C is a 55-inch 4K UHD commercial display for digital signage, offices, retail and transit environments. It delivers 500 nits brightness, runs Android 14 with Pro AV integration, and supports landscape or portrait use. Procure.ae supplies the ViewSonic CDE5514-2C in the UAE.
The CDE5514-2C uses a 3840 x 2160 native panel with 1,200:1 typical contrast, rising to 2,000:1 with DCR enabled. Its 8 ms response time and 178-degree horizontal and vertical viewing angles are part of the manufacturer's specifications. An anti-glare coating with 3H hardness and 25% haze covers the screen. A quad-core ARM Cortex-A73 processor with 4 GB RAM and 32 GB storage runs Android 14, and auto signal failover keeps USB media playing if the main source is lost.
The manufacturer states that the display is designed for IT and AV professionals and integrates with leading Pro AV control systems and ViewSonic Manager. Its RS-232 port, RJ45 connection and USB-C input with DisplayPort 1.2 support AV and IT setups. The 400 x 400 mm VESA pattern supports wall mounting, and the set measures 1233 x 703.5 x 62 mm, with a net weight of 12.95 kg.
Key features
Specifications
| Key Features | Auto signal failover for USB media, ViewSonic Launcher, ViewSonic Manager remote control, AirSync wireless presentation, Landscape and portrait, Pro AV control integration |
| Model | CDE5514-2C |
| Type | Digital Signage Display |
| Aspect Ratio | 16:9 |
| Backlight | DLED |
| Bezel Size | 9.9 mm (all sides) |
| Brightness | 500 nits |
| Contrast Ratio | 1,200:1 (typical); 2,000:1 (DCR) |
| Orientation | Landscape and portrait |
| Panel Technology | LCD |
| Resolution | 3840 x 2160 (4K UHD) |
| Response Time | 8 ms |
| Screen Size | 55 inch |
| Viewing Angle | 178° horizontal, 178° vertical |
| Operating System | Android 14 |
| Processor | Quad-core ARM Cortex-A73 |
| RAM | 4 GB |
| Storage | 32 GB |
| Ethernet | RJ45 × 1 (10/100M, shared via USB-C) |
| Input Voltage | 100–240 V AC ±10% |
| Ports | RS-232 × 1, SPDIF × 1, RJ45 × 1, USB 2.0 × 2, USB-C × 1 |
| Serial Port | RS-232 × 1 |
| USB-C Ports | USB-C × 1 (DP 1.2, USB 2.0, 15 W PD, Ethernet sharing) |
| Wi-Fi | WiFi slot × 1 |
| Power Consumption | 66.35 W |
| Dimensions | 1233 x 703.5 x 62 mm |
| Operating Humidity | 20% to 80% RH, non-condensing |
| Operating Temperature | 0 to 40 °C |
| VESA Mount | 400 x 400 mm |
| Weight | 12.95 kg |
