SpecktronInteractive Flat PanelsSKU CDX-86i
Specktron CDX 86” Ultra HD Interactive Touchscreen – Model CDX-86i
The Specktron CDX 86” Ultra HD Interactive Touchscreen – Model CDX-86i is a interactive flat panel available in the UAE from Procure.ae.
The Specktron CDX 86” Ultra HD Interactive Touchscreen (Model CDX-86i ) is the ultimate solution for modern classrooms, conference rooms, and collaborative workspaces. Featuring a massive 86-inch interactive display with stunning Ultra HD 4K resolution , this advanced touchscreen delivers crystal-clear visuals and smooth, responsive touch performance for a truly engaging experience. With multi-touch support, seamless connectivity, and an intuitive interface, the CDX-86i interactive panel makes presentations, lessons, and brainstorming sessions more dynamic and effective. Compatible with a.
It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.
Screen Size
86 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
450 nits
Touch Technology
Infrared
- Ultra HD 4K Resolution
- 86-Inch Interactive Display
- Multi-Touch Technology
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Ultra HD 4K Resolution
Delivers breathtaking clarity and vibrant colors for presentations and media.
02
86-Inch Interactive Display
Expansive screen size ideal for large spaces and group collaboration.
03
Multi-Touch Technology
Supports multiple users interacting simultaneously for enhanced group work.
04
Integrated Android System
Built-in operating system for easy access to apps and tools.
05
Seamless Device Connectivity
Connects effortlessly with laptops, tablets, and mobile devices.
06
Anti-Glare Glass
Reduces reflections and eye strain for comfortable extended use.
07
Magnetic Stylus Support
Includes precise, easy-to-store stylus for accurate annotation and drawing.
08
Robust Security Features
Protects sensitive data and ensures safe operation in institutional settings.
Specifications
43 specificationsGeneral
Key FeaturesTouch: 20-point / 50-point multi-touch
What's in the BoxST-Series Wireless Dongle, Camera with Mic
Display
BacklightDirect LED
Brightness450 nits
CameraCamera
Color Depth10-bit (1.07 billion colours)
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Screen Size86 inch
Touch Accuracy±1 mm
Touch Points50-point multi-touch
Touch Resolution32768 x 32768
Touch Response Time< 5 ms
Touch TechnologyInfrared
Viewing Angle178° (H) / 178° (V)
Performance
Operating SystemAndroid 12
RAM8 GB
Storage128 GB / 256 GB
Audio
Audio InPC audio in × 1
Audio OutHeadphone out × 1, Line out × 1
MicrophoneMic
Speaker Output2 × 20 W
Speaker TypeBuilt-in
Connectivity
BluetoothBluetooth 5.2
EthernetRJ45 (Gigabit) × 2
HDMI InputsHDMI In × 2
HDMI OutputsHDMI Out × 1
OPS SlotOptional
Serial PortRS-232 × 1
Touch USB PortsTouch USB × 2
USB PortsUSB 2.0 × 3, USB 3.0 × 2, USB-C × 1
USB-C PortsUSB-C × 1
VGA InputVGA × 1
Wi-FiWi-Fi 6E (802.11ax)
Power
Power Consumption< 400 W
Standby Power0.5 W
Physical
Dimensions1953.96 x 1173.62 x 90.6 mm
Operating Humidity10% to 80% RH
Operating Temperature0°C to 40°C
Shipping Dimensions2160 x 1335 x 230 mm
Surface ProtectionTempered glass with Mohs level 9
VESA Mount800 x 400 mm
Weight67 kg
Downloads
Manufacturer documents for the Specktron CDX 86” Ultra HD Interactive Touchscreen – Model CDX-86i — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What is the Specktron interactive flat panel used for?
The Specktron CDX 86” Ultra HD Interactive Touchscreen (Model CDX-86i ) is the ultimate solution for modern classrooms, conference rooms, and collaborative workspaces. Featuring a massive 86-inch interactive display with stunning Ultra HD 4K resolution , this advanced touchscreen delivers.
Does it include installation and warranty?
Procure.ae can arrange installation and provides manufacturer-backed warranty support. Contact us for the full warranty details applicable to this model.
Does this interactive panel support multi-touch and on-screen writing?
Yes — it uses Infrared touch technology, so multiple users can write and interact at the same time.
Can I run apps on it without connecting a PC?
Yes — it runs Android 12, so you can open apps, whiteboard, and browse without a separate computer.
