Sony Full HD PTZ Conference Camera – BRC-H800

The Sony BRC-H800 is a Full HD PTZ conference camera for meeting rooms and lecture halls. It pairs a 1.0-type sensor with a 12x optical zoom and 2x clear image zoom. Two 3G-SDI outputs and HDMI connect to switchers and recorders, and PoE+ or DC power simplifies installation. Procure.ae supplies the Sony BRC-H800 across the UAE.

The BRC-H800 has a 1.0-type back-illuminated Exmor R CMOS sensor with approximately 14.2 megapixels effective and a 12x optical zoom, with a focal length of 9.3 to 111.6 mm. Clear image zoom extends reach to 2x at 1920 x 1080. Pan is ±170 degrees and tilt runs from +90 to -30 degrees, with pan and tilt speeds of 0.3 to 60 degrees per second in normal speed mode. The camera stores 100 preset positions and 16 PTZ trace memories, and it offers colour matrix, gamma and knee adjustments for picture tuning.

The BRC-H800 suits rooms where a single HD camera must feed SDI equipment and be controlled over the network. It accepts VISCA RS-422 and VISCA over IP for control systems. Day/Night and Visibility Enhancer settings are included, and camera tracking data output is available with firmware V2.10 or later. It runs on DC 10.8 to 13.2 V or PoE+ (IEEE 802.3at) and mounts to a ceiling with the supplied brackets.

Resolution

1920 x 1080 (Full HD)

Speed

Pan and tilt 0.02 to 60°/s (depending on speed type setting)

Type

PTZ Camera

Weight

4.3 kg

Key features

Full HD output

1920 x 1080 over two 3G-SDI outputs and HDMI.

12x optical zoom

9.3 to 111.6 mm focal length, with 2x clear image zoom at 1080p.

Picture controls

colour matrix, gamma, black level and knee settings with picture profile presets.

VISCA control

VISCA RS-422 and VISCA over IP for control systems.

Preset memory

100 preset positions and 16 PTZ trace memories.

Power options

DC 10.8 to 13.2 V or PoE+ (IEEE 802.3at compliant).

Tracking data

camera tracking data output with firmware V2.10 or later.

Ceiling mount

mounts with the supplied ceiling brackets and an HDMI cable fixing plate.

Specifications

General
Key Features	Full HD output, 12x optical zoom, 2x clear image zoom, 3G-SDI and HDMI outputs, PoE+ power, VISCA over IP control, ceiling mount
Model	BRC-H800
Type	PTZ Camera
What's in the Box	IR remote commander unit, ceiling brackets (2), wire rope, M3 x 8 and M4 x 8 screws, HDMI cable fixing plate

Display
Camera	1.0-type back-illuminated Exmor R CMOS, approx. 14.2 MP effective
Resolution	1920 x 1080 (Full HD)
Viewing Angle	64.6° horizontal (wide end)
Zoom	12x optical; 2x clear image zoom; digital zoom not available

Performance
Speed	Pan and tilt 0.02 to 60°/s (depending on speed type setting)
Storage Conditions	-20 to +60 °C

Connectivity
Input Voltage	DC 10.8 to 13.2 V
PoE	PoE+ (IEEE 802.3at compliant)
Ports	3G-SDI × 2, HDMI × 1, external sync BNC × 1, VISCA RS-422 and VISCA over IP (RJ-45)
Protocols	VISCA RS-422, VISCA over IP

Power
Power Consumption	19.0 W max (DC 12 V); 23.0 W max (PoE+)

Physical
Color	Black and White
Dimensions	198 x 260 x 238 mm
Mounting	Ceiling mount (with ceiling bracket)
Operating Temperature	0 to 40 °C
Weight	4.3 kg
