Siglent SDS1104CFL 100MHz Four Channel Digital Oscilloscope
- SKU: SDS1104CFL
Actual Stock Can Be Confirmed After Placing the Order.
PRODUCT OVERVIW Siglent’s SDS1000CFL family of scopes offer faster sampling rates and higher bandwidths than other Siglent SDS1000 families of scopes. The CFL’s provide up to four channels with an external trigger input channel and bandwidths up to 300 MHz. With a set of... See More
PRODUCT OVERVIW
Siglent’s SDS1000CFL family of scopes offer faster sampling rates and higher bandwidths than other Siglent SDS1000 families of scopes. The CFL’s provide up to four channels with an external trigger input channel and bandwidths up to 300 MHz. With a set of separate vertical controls for each input channel, you don’t need to worry about accidentally modifying the wrong trace. No more switching between channels as found in some other 2 and 4 channel oscilloscopes. Powerful triggering and analysis capabilities make it easy to capture and analyze waveforms, greatly improving the test efficiency.
Key Features
- 7″ Color TFT LCD display
- 2/4 channels, Bandwidth: 70MHz-300 MHz
- Single channel real-time sampling rate is: 2GSa/s, Equivalent sampling rate is 50GSa/s
- Memory depth: 24Kpts
- Trigger types: Edge, Pulse, Video, Slope and Alternative
- Powerful Digital Filter function and Waveform recorder function
- Auto measurement of thirty two parameters
- 2 / 4 groups’ reference waveforms. 20 groups of captured waveforms and 20 groups of setups. Internal save/recall function and USB flash drive save/recall function.
- Cursor types: Manual mode, Track mode and Auto mode
- Channel waveform and its FFT waveform display on split screen or full screen
- Four Screen display styles: Classical, Modern, Tradition, Succinct
- Multiple Language User Interface
- Supports built-in online help system
- Standard interfaces: Dual USB Host; USB Device; LAN Port; Pass/Fai Out
No datasheet available.
