Samsung OHF Series 75-inch High Brightness Digital Signage Display – OH75F
The Samsung OH75F is a 75-inch high brightness digital signage display in the OHF series (model code LH75OHFPLBC/UE), with 2,500 nits typical brightness, a 1920 x 1080 VA panel and HDBaseT input. It suits large indoor venues that need a bright display. Procure.ae, an authorised reseller of Samsung, supplies it across the UAE.
The OH75F has a 1920 x 1080 VA panel with 2,500 nits typical brightness, 5,000:1 native contrast and 10,000:1 dynamic contrast. Its viewing angle is 178 degrees horizontal and vertical, and its 6 ms response time is listed by the manufacturer. Inputs include two HDMI, an HDBaseT input over LAN, and RS232 and RJ45 inputs for control. Protection glass is fitted over the panel.
The OH75F is the 75-inch model in the OHF high brightness range, between the 55-inch OH55F and the 85-inch OH85F. Its 1774.8 x 1053.4 x 120 mm body weighs 142 kg and has a 59.8 mm bezel. The manufacturer's specifications list 1,400 W power draw in on mode and 0.5 W in sleep mode. The manufacturer also lists no MagicInfo daisy-chain videowall support for this model.
Key features
Specifications
| Key Features | 2,500 nits brightness, 10,000:1 dynamic contrast, protection glass, HDBaseT input, RS232 and RJ45 control, no daisy-chain videowall support |
| Model | OH75F |
| Type | High Brightness Digital Signage Display |
| Bezel Size | 59.8 mm |
| Brightness | 2,500 nits (typical) |
| Color Gamut | 70% |
| Contrast Ratio | 5,000:1 (native); 10,000:1 (dynamic) |
| Panel Technology | VA |
| Resolution | 1920 x 1080 (Full HD) |
| Response Time | 6 ms |
| Screen Size | 75 inch |
| Viewing Angle | 178° horizontal / 178° vertical |
| HDMI Inputs | 2 |
| Input Voltage | 100–240 V AC, 50/60 Hz |
| Inputs | HDMI × 2, HDBaseT (LAN), RS232 In, RJ45 In |
| Ports | HDMI In × 2, HDBaseT In, RS232 In, RJ45 In, Audio Out × 1, USB |
| USB Ports | Yes |
| Power Consumption | 1,400 W (on mode) |
| Standby Power | 0.5 W (sleep mode) |
| Dimensions | 1774.8 x 1053.4 x 120 mm |
| Operating Humidity | 10% to 80%, non-condensing |
| Shipping Dimensions | 1946 x 1252 x 495 mm |
| Shipping Weight | 188 kg |
| Surface Protection | Protection glass |
| Weight | 142 kg |
